High-performance Industrial Computers | VFACEH X86 Series
VINCANWO GROUP
| Availability: | |
|---|---|
| Quantity: | |
| SKU | VFACEH-104 | VFACEH-121 | VFACEH-15 | VFACEH-156 | VFACEH-17 | VFACEH-173 | VFACEH-185 | VFACEH-19 | VFACEH-215 |
| Screen Size | 10.4” | 12.1” | 15” | 15.6” | 17” | 17.3” | 18.5” | 19” | 21.5” |
| Resolution | 1024x768 | 1024x768 | 1024x768 | 1920x1080 | 1280x1024 | 1920x1080 | 1920x1080 | 1280x1024 | 1920x1080 |
| Viewing Angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 85/85/80/80 | 80/80/60/80 | 89/89/89/89 | 85/85/85/80 | 89/89/89/89 |
| Brightness | 500 cd/㎡ | 500 cd/㎡ | 350 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ | 400 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ |
| Contrast Ratio | 900:01:00 | 1200:01:00 | 1000:01:00 | 3000:01:00 | 1000:01:00 | 600:01:00 | 1000:01:00 | 1000:01:00 | 1000:01:00 |
| Touchscreen | Capacitive, Resistive | ||||||||
| Controller | USB interface | ||||||||
| Durability | Capacitive: ≥ 5M times, Resistive: : ≥ 100,000 times | ||||||||
| Chipset | D81 (LGA1150) | H310(LGS1151) | D81 (LGA1150) | H610 (LGA1700) | H310 (LGA1151) | H610 (LGA1700) | |||
| Memory Type | 2x DDR3 4G, 8G, 16G | 2x DDR4 4G, 8G, 16G, 32G | |||||||
| Storage Type | 1x mSATA, 1x SATA | 1x M.2 Slot, support M.2 2260/2280 | |||||||
| Ethernet / LAN | 2x RTL8111 | ||||||||
| Serial / Com | 2x RS232 (COM2 option RS485) | ||||||||
| USB | Front 1x USB, Rear 4x USB | ||||||||
| Video Outputs | 1x HDMI, 1x VGA | ||||||||
| Expansion Slots | 1xMini-PCIE WiFi, 1x Mini PCIE WiFi & Bluetooth or 4G LTE | ||||||||
| Operating Systems | Windows, Linux | ||||||||
| Dimension | 309x245.4x66.7mm | 310x273.1x66.8mm | 366x310x71.2mm | 402.7x269.7x70.4mm | 397.8x354x71.4mm | 446.2x296.2x73.1mm | 476.4x339.3x70.3mm | 439x386.5x72.6mm | 550x365.7x72.4mm |
| Mounting Hole Size | 301x237mm | 301x256mm | 352x298mm | 389x258mm | 384x343mm | 432x285mm | 464x327mm | 426x374mm | 533x347mm |
| Gross Weight | 3 .54kg | 3.52kg | 4.68kg | 4.84kg | 6.00kg | 5.68kg | 6 .54kg | 7.00kg | 8.08kg |
| Mounting Options | Embedded, Wall Mount, Desktop Stand | ||||||||
| Operating Temperature | -30℃ ~ +70℃ | ||||||||
| Storage Temperature | -40℃ ~ +80℃ | ||||||||
| Humidity Rage | 5% - 95% Non-condensing | ||||||||
| Power | Standard Power: Optional 12V AC/DC Adapter: 5A, 60W, Optional Input Voltage Range 9 – 36V DC | ||||||||
>Advantages:
The VFACEH X86 Series high-performance industrial computers offer the most advantages for industrial applications:
Reliable Operation: The industrial-grade components and rugged construction of the VFACEH X86 Series ensure reliable operation in harsh industrial environments. These computers are designed to withstand extreme temperatures, vibrations, and other challenging conditions.
High Performance: Equipped with powerful Intel X86 processors, the VFACEH X86 Series industrial computers deliver high-speed computing performance for demanding industrial applications. This allows for efficient data processing and improved productivity.
Customization Options: The VFACEH X86 Series industrial computers come with multiple expansion slots and optional features, such as solid-state drives and redundant power supplies, allowing for customization to meet specific industrial requirements.
Wide Operating Temperature Range: The VFACEH X86 Series industrial computers have a wide operating temperature range, allowing them to function effectively in extreme temperatures without compromising performance or reliability.
Connectivity Options: With multiple LAN ports and expansion slots, the VFACEH X86 Series industrial computers offer versatile connectivity options for seamless integration into industrial networks and systems.
Overall, the VFACEH X86 Series high-performance industrial computers provide a reliable, high-speed computing solution for industrial applications, offering durability, customization options, and connectivity features to meet the needs of demanding industrial environments.
>Applications:
The VFACEH X86 Series high-performance industrial computers are well-suited for a variety of industrial applications that require reliable computing power in challenging environments. The most common applications include:
Industrial Automation: The VFACEH X86 Series industrial computers can be used in industrial automation systems to control and monitor manufacturing processes, machinery, and equipment. Their high-performance capabilities and rugged design make them ideal for real-time data processing and control tasks.
Manufacturing: Industrial computers from the VFACEH X86 Series are commonly used in manufacturing facilities for tasks such as production monitoring, quality control, inventory management, and process optimization. Their high-speed computing power and durability ensure smooth operation in manufacturing environments.
Transportation and Logistics: The VFACEH X86 Series industrial computers can be deployed in transportation and logistics applications for tasks such as fleet management, route optimization, vehicle tracking, and warehouse management. Their rugged construction and reliable performance make them suitable for use in vehicles and warehouses.
Energy and Utilities: Industrial computers from the VFACEH X86 Series are used in the energy and utilities sector for tasks such as monitoring and controlling power generation, distribution, and consumption. Their high-performance capabilities and robust design make them well-suited for critical infrastructure applications.
Oil and Gas: The VFACEH X86 Series industrial computers are commonly used in the oil and gas industry for tasks such as remote monitoring, data acquisition, and control of drilling operations, pipelines, and refineries. Their durability and reliability make them suitable for use in harsh and remote environments.
Aerospace and Defense: Industrial computers from the VFACEH X86 Series are utilized in aerospace and defense applications for tasks such as flight simulation, radar processing, mission planning, and surveillance. Their high-speed computing power and rugged design make them suitable for mission-critical applications.
Overall, the VFACEH X86 Series high-performance industrial computers are versatile and reliable solutions for a wide range of industrial applications that require robust computing power in challenging environments.
