| Model | VW100 |
| Processor | Intel® Core™ 4th/5th Gen 13/15/17 Processor | Intel®Core™ 8th/10th Gen 13/15/17 Processor |
|
| Memory | 2*DDR3 support 4G/8G/16G | 2*DDR4 support 4G/8G/16G/32G |
| Storage | 1*mSATA+1*SATA（2.5”Mechanical hard disk capacity ≤2TB） | 1*M.2+1*SATA（2.5” Mechanical hard disk capacity ≤2TB） |
| Net work | 2*Intel |210/1211 |
| COM | 6 *RS232（COM1-4 optional 232/485） |
| USB | 4 *USB 3.0, 2 *USB2.0 |
| Display | 1 *HDMI, 1 *VGA |
| Other interfaces | 1*AUDIO (2in1), 1*nano SIM car slot |
| Expand slot | 1*MINI-PCIE support WiFi/LTE 4G | 1*M.2(KEY E Wifi&BT 2230)/
1*M. 2(KEY B 4G/5G LTE 3052) |
| Operating system | Windows7.8.10/Linux | Windows10.11/Linux |
| Power Input | DC12V |
| Size included rack (mm) | 195x169x60 |
| Individual Gross Weight (KG) | 1.65 |
| Mounting Options | Wall-mounted / Desktop |
| Operating Temperature | -20 ~ +60℃ |
| Storage Temperature | -20 ~ +70℃ |
Storage Humidity *Non-condensing | 5 ~ 95% |
| Packaging Information |
| GW100 | 1 *Master, 1 *Adapter, 1* Power Supply Cable |
| GW100-4L | Optional to upgrade 4 *Intel l1210/l1211+4 *USB2.0 |
| GW100-GP | Optional to upgrade 4 *input/4 *output GPIO, optional 9 ~ 36V |
