About the Series
Intel 11th Generation CPU
The 760H2 Seriesis powered by an Intel 11th Generation Core i5 CPU, ensuring exceptional processing power and performance. With this advanced processor, users can experience seamless multitasking, faster data processing, and enhanced overall system responsiveness. Despite its small chassis, this deceptively compact computer packs a powerful punch with its Core i5 processor.
Windows 11
This box PC comes equipped with the Windows 11 operating system because of the powerful Intel 11th Generation Core i5 CPU. With Windows 11, users can enjoy an enhanced and intuitive user interface, improved security features, and seamless compatibility with a wide range of software applications. The advanced capabilities of Windows 11 further enhance the productivity and user experience of the 760H2, making it an excellent choice for applications requiring a reliable and modern industrial computer.
| SKU | 760H2 | ||||||||
| Processor | Intel® Core™ 11th Gen 13/15/17 Processor | ||||||||
| Memory | 1*DDR4 8G/16G | ||||||||
| Storage | 1*mSATA. 1*SATA3.0 | ||||||||
| Net work | 2 *Realtek RTL8111+2*Intel l211 | ||||||||
| COM | 6 *RS232（COM1-2 support RS485） | ||||||||
| USB | 2*USB 3.0, 2*USB2.0 | ||||||||
| Display | 1*HDMI, 1*DP | ||||||||
| Expand slot | 1*MINI-PCIE WIFI, 1 *MINI PCIE 4G/5G | ||||||||
| Operating system | Windows7.8.10/Linux | ||||||||
| Power Input | DC12V | ||||||||
| Size included rack (mm) | 235x175.5x58.5 | ||||||||
| Individual Gross Weight (KG) | 1.65 | ||||||||
| Mounting Options | Wall-mounted / Desktop | ||||||||
| Operating Temperature | -20 ~ +60℃ | ||||||||
| Storage Temperature | -20 ~ +70℃ | ||||||||
Storage Humidity *Non-condensing | 5 ~ 95% | ||||||||
| Packaging Information | 1 *Master, 1 *Adapter, 1* Power Supply Cable | ||||||||
