| Model | ST-T208 | ST-T212 | ST-T316 | ST-T424 | ST-T2125 |
| Appearance specifications | 2U 8 rotors | 2U 12 rotors | 3U 16 rotors | 4U 24 rotors | 2U 25 rotors |
| Controller |
|
| RAID level | 0 ，1 ，5 ，6 ，10 ，50 ，60.、JBOD |
| Host Connection |
|
| Management Port | Gigabit Ethernet IPMI2.0 |
| Applicable platforms | Windows ，Linux ，Solaris ，HP-UX ，VMware ，MAC OS ，AIX |
| Storage Media |
|
| Disk Expansion | Direct Connection | Direct Connection, Extension | Extended Mode | Extended Mode | Extended Mode |
| Number of Disks | 8 (Optional) | 12 (Optional) | 16 (Optional) | 24 (Optional) | 25 (Optional) |
| Storage Capacity | SAS3: | SAS3: | SAS3: | SAS3: | SAS3: |
| Max 192TB | Max 288TB | MAX 384TB | Max 576TB | Max 600TB |
| SATA3: | SATA3: | SATA3: | SATA3: | SATA3: |
| Max 192TB | Max 288TB | MAX 384TB | Max 576TB | Max 600TB |
| Hard disk specifications | 2. 5" 300GB/600GB/1.2TB/2.4TB SAS3 Hard Disk |
| 3. 5" 2TB/4TB/6TB/8T/10T /12TB/14TB/16TB/18TB/20TB/24TB/SAS3 Hard Disk |
| 3. 5" 2TB/4TB/6TB/8T/10T /12TB/14TB/16TB/18TB/20TB/24TB/SATA3 Hard Disk |
| Supports enterprise level SSDs (no need to replace hard drive bays) |
| Management Function |
|
| System Management | SkyTalent Storage system management software |
| Supports B/S architecture and can be managed through a web interface |
| Network Management | Supports SNMP, Email alerts |
| Support management interface alarms, Support daily record information export |
| Storage Management | Front end management based on display and serial port |
| Web browser based remote management method (SSL based secure connection) |
| Multiple RAID levels and stripe sizes |
| Local and global hot spare, supporting configuration of multiple global hot spare disks |
| Online hard disk transfer and array roaming |
| Hard disk SMART |
| Energy Saving Management | Support MAID, System energy saving 20% ~ 30% |
| Path Management |
|
| Data Management |
|
| General Characteristics |
|
| System Power Supply | Redundance 550W | Redundance 800W | Redundance 800/1200W | Redundance 800/1200W | Redundance 800/1200W |
| Power Supply Requirements | 100 ~ 240VAC (+/-10%), 47 ~ 63HZ, Auto-Ranging , PFC |
| Temperature | Working environment: - 10℃ ~ +35℃, Non-working environment: - 40℃ ~ +70℃ |
| Humidity | Working environment: 8% ～ 90% , Non-working 5%～95% |
