| SKU | FWS-101 | FWS-156 | FWS-215 |
| Screen Size | 10.1" | 15.6" | 21.5" |
| Resolution | 1280*800 | 1920*1080 | 1920*1080 |
| Viewing Angle | 80/80/80/80 | 89/89/89/89 | 89/89/89/89 |
| Brightness | 330 cd/m2 | 250 cd/m2 | 250 cd/m2 |
| Contrast Ratio | 600:1 | 3000:1 | 1000:1 |
| Touch Screen | Capacitive |
| Controller | USB interface |
| Durability | ≥ 500W times |
| Processor | Intel Processors |
| Memory | Under 5th Generation: DDR3, 4G / 8G | Above 6th Generation: DDR4, 4G / 8G / 16G |
| Storage | Under 5th Gen: 1*mSATA/1*SATA (2.5" Mechanical hard drive capacity ≤ 2TB) | Above 6th Gen: 1*M.2/1*SATA (2.5" Mechanical hard drive capacity ≤ 2TB) |
| Network | 1*LAN | 2 *LAN |
| COM | 2 *RS232 (COM 2, optional RS485) | 2 *RS232 (COM2, optional RS485) expand to 5COM |
| USB | 4 *USB2.0 |
| Display | 1 *HDMI, 1 *VGA |
| ExpandSlot | Under 5th Gen: 1*Mini PCIE WiFi&BT or 4G LTE | Above 6th Gen: 1*M.2 (KEY E WiFi&BT 2230)/1*M.2 (KEY B 4G/5G LTE 3052) |
| Operating System | Windows / Linus |
| Sensor | Optional front IC/ID card swiping, camera, scanning code |
| Dimensions (mm) | 283*228.2*52.1 | 418*332*58.3 | 544*410.6*59.4 |
| Hole Sizes (mm) | 272*218 | 396*324 | 533*397 |
| Weight (KG) | 0.95 | 1.84 | 3.92 |
| Mounting Options | Embedded / Wall-mounted / Desktop |
| Operating Temperature | -0 ~ +50℃ | -0 ~ +50℃ | -0 ~ +50℃ |
| Storage Temperature | -20 ~ +60℃ | -20 ~ +60℃ | -20 ~ +60℃ |
| Storage Humidity | 5 ~ 90% | 5 ~ 90% | 5 ~ 90% |
| Power Input | DC -12V (Optional 9 ~ 36V Wide-range Voltage) |
| Packaging Information |
| FWS | 1 *Master, 1 *Adapter, 1* Power Supply Cable, 4 *hooks, 1 *Manual, 1 *Warranty Card |
| FWS-1 | Available to upgrade front IC/ID card swiping |
| FWS-C | Available to upgrade front Camera |
| FWS-S | Available to upgrade front Scanning Code |
| FWS-I/C/S | Available to upgrade front IC/ID card swiping / camera / scanning code |
