IPC-2U
VINCANWO GROUP
| Availability: | |
|---|---|
| Quantity: | |
| Model | IPC-2U | ||||||||
| Primary Components | Motherboard | B75/3rd gen/275W(2*D3/5*SA/1*M2/PCIE X16*1/X1*1/PCI*2) B85/4th gen/275W(4*D3/5*SA/1*M2/PCIE X16*1/X4*2/PCI*4) H310/6th ~ 9th gen/275W(2*D4/3*SA/1*M2/PCIE X16*1/X4*1/PCI*2) H610/12th ~ 14th gen/500W (2*D4/3*SA/1*M2/PCIE X16*2/X4*3) | |||||||
| Chipset | H310 H670 | ||||||||
| Processor Model | 12th/11th/10th/9th/8th/7th/6th/5th/4th | i3/i5/i7 Phytium D2000 dual-network, D2000 quad-network, FT2000 dual-network Zhaoxin U6580 single-network, U6780A single-network, 6640MA dual-network Hygon C86-4G 3490 Dual-SIM | ||||||||
| Memory Type | DDR3, DDR4 | ||||||||
| Memory Support | 4GB, 8GB, 16GB, 32GB, PC-DDR4 supports 64GB | ||||||||
| Storage Type | 1x MSATA | 1x M.2 SATA | 1x M.2 NVME protocol, 4x SATA 3.0 | ||||||||
| Storage Support | MS:128GB~512GB | M.2: 128GB~1TB | ||||||||
| Operating Systems | Windows | Windows 10 IoT, Windows 10 Pro, Windows 11 Pro | |||||||
| Linux | Linux Ubuntu 20.04 or above (Contact your sales rep for more information) | ||||||||
| Peripherals & Wireless Connectivity | WiFi | Optional 802.11 a/b/g/n/ac/ax Wi-Fi 6 | |||||||
| Bluetooth | Optional Bluetooth 5.3 | ||||||||
| External I/O Ports | USB | 2x front USB 2.0 8x rear USB 3.2 | |||||||
| Serial/COM | 2x rear RS232, expandable to 4x RS232 COM3/4 supports RS422/485 | ||||||||
| Ethernet / LAN | 1x Gigabit I219V, 1x 2.5 Gigabit I226 1x RLT8111 Gigabit Ethernet adapter, supports Wake-on-LAN and PXE functionality | ||||||||
| Video Outputs | 1x VGA, 1x DVI-I, 1x HDMI | ||||||||
| Audio Ports | 1 x LINE_IN, 1 x LINE_OUT 1 x MIC_IN Integrated Realtek ALC4080 HD digital audio decoder | ||||||||
| PS interface | 1x PS2 | ||||||||
| Expansion Slots | Others | 2x PCI-E X16 2x PCI-E X4 2x PCI 1x PCI-E x16_1 interface, for connecting a discrete graphics card (PCI-E x8 signal) 1x PCI-E x16_2 interface, for connecting a discrete graphics card (PCI-E x4 signal) 1x PCI-E x8 interface 1x PCI-E x1 interface | |||||||
| LPT parallel port | Expandable to LPT | ||||||||
| Power | Power Supply | ATX power supply Recommended to use a power supply of 200W or above | |||||||
| Weight / Dimensions | Weight | 13.60 kg | |||||||
| Dimensions | 482x400x88.5 mm | ||||||||
| Thermal & Environmental | Operating Temperature | -20°C ~ 60°C | |||||||
| Storage Temperature | -30°C ~ 70°C | ||||||||
| Cooling Solution | high-RPM fan | ||||||||
| Humidity Range | 10% – 95% Non-condensing | ||||||||
| Enclosure | Material | Aluminum | |||||||
| Color | Black | ||||||||
| Led Indicator Light | HDD Access, Power | ||||||||
| Mounting Options | Rack-mount, Desktop | ||||||||
Key Features:
19‑inch standard 2U rackmount design
Robust steel enclosure for durability and EMI protection
Support for ATX/mATX/mini‑ITX motherboards (depending on model)
Multiple 2.5”/3.5” drive bays for flexible storage expansion
Front‑panel USB ports, power/reset buttons, and LED status indicators
Efficient cooling system with front‑to‑rear airflow and optional fan upgrades
Support for standard ATX or redundant power supplies
Well‑organized cable management for easier installation and maintenance
Applications:
Industrial automation and control systems
Network security appliances and firewalls
Edge computing and communication servers
Data acquisition and monitoring systems
Transportation, energy, and IoT gateway solutions
For more detailed specifications or to inquire about custom configurations, please contact Vincanwo Group.
