| Model | 120GQ-TNRT |
| Machine Frame | 1U rack |
| CPU | Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon |
| Chipset | Intel® C621A |
| RAM | 16pcs of memory slots
max supports 6TB RECC
3200/2933 MHZ |
| Hard Disk Slot | 2pcs of NVME hot swappable hard drive slots |
| Hard Disk Specifications | 2.5" NVME hard disk |
| CPU card | Max supports 4pcs of GPU cards |
| Card RTX A6000, A40, A16, A100, RTX A5000, A30, A2 |
| Network Card | 2pcs of RJ45 10GB |
| RAID | RAID 0，1，5，10 |
| Display Controller | 1 x VGA |
| External Device Ports | USB 3.0 |
|
| CD Driver | N/A |
| Cooling Action | 9pcs of high speed fans |
| Power Supply | 2000W high speed power supply
80PLUS certification |
| Management | IPMI 2.0 interface |
| Operating System | Windows, Linux |
| Temperature | Working Environment: - 10℃ ~ + 35℃
Non-working Environment: - 40℃ ~ + 70℃ |
| Humidity | Working Environment: 8%～90%
Non-working Environment: 5%～95% |
| Product Size (mm) | 894 x 437 x 43 |
| Product Weight (kg) | 21.8 |
| Accessories | Installation guide rail / screw pack |
The 120GQ-TNRT GPU system has several benefits, including:
Scientific virtualization: The system is optimized for scientific virtualization.
High performance computing: The system is optimized for high performance computing.
Rendering: The system can be used for rendering.
AI/deep learning training: The system can be used for AI/deep learning training.
NVIDIA vGPU desktop and application virtualization: The system supports NVIDIA vGPU desktop and application virtualization solutions.
Management tools: The system supports management tools such as SuperCloud Composer, Supermicro Server Manager (SSM), and Supermicro Update Manager (SUM).
GPUs are companion processors to CPUs that can significantly increase a system's processing capabilities and speed. They are well-suited for tasks that require parallel operations, such as machine learning and image processing.
