| SKU | 120TP-DTTR |
| Machine Frame | U rack mounted, Dual nodes |
| CPU | Dual Socket P+ (LGA-4189) |
| 3rd Generation Intel® Xeon | |
| Chipset | Intel® C621A |
| RAM | 16pcs of memory slots, max supports 4TB |
| DDR4 RE G2933/32006MHZ RAM | |
| Hard Disk Slot | 4pcs of hot swappable hard drive slots |
| Hard Disk Specifications | 2.5" SATA hard disk |
| Expansion Slot | 2 PCIe 4.0 x16 (LP), 1 PCIe 4.0 x 8 |
| Network Card | 2pcs of Gigabit Ethernet ports |
| RAID | N/A |
| Display Controller | 1 x VGA |
| External Device Ports | 2 x USB 3.0 |
| CD drive | N/A |
| Cooling action | 2 x 40mm high speed fans |
| Power Supply | 1000W(1+1) redundant power supply |
| 80PLUS Platinum certification | |
| Management | IPMI 2.0 interface |
| Operating System | Windows, Linux |
| Temperature | Working Environment: - 10℃ ~ + 35℃ |
| Non-working Environment: - 40℃ ~ + 70℃ | |
| Humidity | Working Environment: 8%～90% |
| Non-working Environment: 5%～95% | |
| Product Size (mm) | 718 × 438 × 43 |
| Product Weight (kg) | 18.1 |
| Accessories | Installation guide rail / screw pack |
120TP-DTTR Twin Server Solution offers the benefits, including:
Space and energy savings
120TP-DTTR Twin Server Solution is a space-efficient variant of the MicroCloud server that can save money and energy.
High performance
Twin servers are designed for demanding applications and offer high computing density and performance.
Energy-efficient cooling
120TP-DTTR Twin Server Solution is designed with optimal airflow to keep operational costs low.
Easy maintenance
120TP-DTTR Twin Server Solution features hot-swappable nodes and redundant power supply modules for easy maintenance and continuous operation.
Scalability
120TP-DTTR Twin Server Solution is scalable and cost-effective, making them a good choice for growing businesses.
Redundancy
120TP-DTTR Twin Server Solution offers advanced redundancy options, with each server node able to be self-sufficient.
Clustering
120TP-DTTR Twin Server Solution offers clustering capabilities within each server.
120TP-DTTR Twin Server Solution is used for a variety of applications, including cloud computing, high performance computing, and datacenter solutions.
