| SKU | ST-T208 | ST-T212 | ST-T316 | ST-T424 | ST-T2125 |
| Appearance specifications | 2U 8 rotors | 2U 12 rotors | 3U 16 rotors | 4U 24 rotors | 2U 25 rotors |
| Controller | |||||
| RAID level | 0 ，1 ，5 ，6 ，10 ，50 ，60, JBOD | ||||
| Host Connection | |||||
| Management Port | Gigabit Ethernet IPMI2.0 | ||||
| Applicable platforms | Windows ，Linux ，Solaris ，HP-UX ，VMware ，MAC OS ，AIX | ||||
| Storage Media | |||||
| Disk Expansion | Direct Connection | Direct Connection, Extension | Extended Mode | Extended Mode | Extended Mode |
| Number of Disks | 8 (Optional) | 12 (Optional) | 16 (Optional) | 24 (Optional) | 25 (Optional) |
| Storage Capacity | SAS3: | SAS3: | SAS3: | SAS3: | SAS3: |
| Max 192TB | Max 288TB | MAX 384TB | Max 576TB | Max 600TB | |
| SATA3: | SATA3: | SATA3: | SATA3: | SATA3: | |
| Max 192TB | Max 288TB | MAX 384TB | Max 576TB | Max 600TB | |
| Hard disk specifications | 2. 5" 300GB/600GB/1.2TB/2.4TB SAS3 Hard Disk | ||||
| 3. 5" 2TB/4TB/6TB/8T/10T /12TB/14TB/16TB/18TB/20TB/24TB/SAS3 Hard Disk | |||||
| 3. 5" 2TB/4TB/6TB/8T/10T /12TB/14TB/16TB/18TB/20TB/24TB/SATA3 Hard Disk | |||||
| Supports enterprise level SSDs (no need to replace hard drive bays) | |||||
| Management Function | |||||
| System Management | SkyTalent Storage system management software | ||||
| Supports B/S architecture and can be managed through a web interface | |||||
| Network Management | Supports SNMP, Email alerts | ||||
| Support management interface alarms, Support daily record information export | |||||
| Storage Management | Front end management based on display and serial port | ||||
| Web browser based remote management method (SSL based secure connection) | |||||
| Multiple RAID levels and stripe sizes | |||||
| Local and global hot spare, supporting configuration of multiple global hot spare disks | |||||
| Online hard disk transfer and array roaming | |||||
| Hard disk SMART | |||||
| Energy Saving Management | Support MAID, System energy saving 20% ~ 30% | ||||
| Path Management | / | ||||
| Data Management | / | ||||
| General Characteristics | |||||
| System Power Supply | Redundance 550W | Redundance 800W | Redundance 800/1200W | Redundance 800/1200W | Redundance 800/1200W |
| Power Supply Requirements | 100 ~ 240VAC (+/-10%), 47 ~ 63HZ, Auto-Ranging , PFC | ||||
| Temperature | Working environment: - 10℃ ~ +35℃, Non-working environment: - 40℃ ~ +70℃ | ||||
| Humidity | Working environment: 8% ～ 90% , Non-working 5%～95% | ||||
Scalability
Storage servers can be easily expanded to meet growing data needs.
Security
Storage servers can use encryption, access controls, and backups to protect data from theft, loss, or damage.
Accessibility
Data stored on a storage server can be accessed from any device with an internet connection.
Cost-effectiveness
Storage servers can be more affordable than traditional data storage options because they eliminate hardware and maintenance costs.
Ease of use
Storage servers can be designed to be simple to use, even for non-technical users.
Data management
Storage servers can simplify data management and improve data retrieval speeds.
Business continuity
Storage servers can be a key part of business continuity plans, ensuring data is safe and recoverable.
High availability
Storage servers can use redundant hardware components and technologies like RAID to ensure reliability and rapid recovery in an emergency.
A storage server , also known as a file server, is a specialized type of server used for storing, securing, and managing data and applications. This server is designed primarily to store and facilitate access to data through the internet or over a shared network.
