SKU | VFACE-19 |
Screen Size | 19" |
Resolution | 1280*1024 |
Viewing Angle | 85/85/80/80 |
Brightness | 250 cd/m2 |
Contrast Ratio | 1000:1 |
Touch Screen | Capacitive, Resistive |
Controller | USB interface |
Durability | Capacitive: ≥5M times / Resistive: ≥100,000 times |
Processor | Intel® Processors |
RAM | 4G/8G/16G/32G |
SSD | under 5th Gen.: 1 * mSATA/1 *SATA(2 .5”Mechanical hard disk capacity ≤2TB) up to 6th Gen.: 1 * M.2/1 *SATA(2 .5” Mechanical hard disk capacity ≤2TB） |
Network | 2 *RTL8111 |
COM | 2 *RS232 (COM2 optional RS485, expansion to 6COM) |
USB | 1* Front USB, 4* Rear USB |
Display | 1 *HDMI, 1 *VGA |
Expansion Slots | under 5th Gen.: 1 * Mini PCIE Wifi&BT or 4G LTE up to 6th Gen.: 1 * M.2(KEY EWifi&BT 2230)/1 * M.2(KEY B 4G/5G LTE 3052) |
Operating System | Windows / Linux |
Dimensions (mm) | 439*386.5*64 |
Mounting Hole Size (mm) | 426*374 |
Gross weight (kg) | 7.00 |
Installation methods | Embedded / Wall mount / Desktop |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
Power Input | 1*12VDC (6A) (Option 9~36VDC Wide-range Power Input) |
Packaging Information | 1 *Master, 1 *Transformer, 1* Power Supply Cable |
>Advantages:
There are the most advantages of the 19" Advance Panel PC VFACE-19:
Large Display: The 19-inch screen size provides a larger viewing area, making it easier to view and interact with content on the panel PC. This is especially useful for applications that require detailed visuals or multiple windows to be displayed simultaneously.
High Resolution: The VFACE-19 offers a high-resolution display, ensuring crisp and clear images and text. This is important for applications that require precise visual representation, such as graphic design or medical imaging.
Rugged Design: The VFACE-19 is designed to withstand harsh environments, making it suitable for industrial applications where the panel PC may be exposed to dust, moisture, or extreme temperatures. Its rugged construction ensures durability and reliability in challenging conditions.
Powerful Performance: The VFACE-19 is equipped with a powerful processor and ample memory, allowing for fast and efficient performance. This is essential for applications that require multitasking, data processing, or running resource-intensive software.
Connectivity Options: The panel PC offers a variety of connectivity options, including USB, Ethernet, and serial ports, making it easy to connect to other devices and systems. This versatility allows for seamless integration with existing equipment and networks.
Overall, the VFACE-19 is a versatile and reliable panel PC that offers a range of features and benefits for businesses looking for a high-performance computing solution. Its large display, high resolution, rugged design, powerful performance, and connectivity options make it a valuable asset for a variety of applications.
>Product Applications:
The 19" Advance Panel PC VFACE-19 is well-suited for a variety of applications across different industries. The most common applications include:
Industrial Automation: The VFACE-19 can be used in industrial automation systems for monitoring and controlling manufacturing processes. Its rugged design and powerful performance make it ideal for harsh industrial environments.
Digital Signage: The large display and high resolution of the VFACE-19 make it perfect for digital signage applications, such as advertising displays, interactive kiosks, and information boards in public spaces.
Retail Point of Sale (POS): The VFACE-19 can be used as a POS system in retail stores, providing a user-friendly interface for processing transactions, managing inventory, and tracking sales data.
Healthcare: In healthcare settings, the VFACE-19 can be used for medical imaging, patient monitoring, electronic health records, and other healthcare applications that require a high-quality display and reliable performance.
Transportation: The VFACE-19 can be integrated into transportation systems for vehicle monitoring, route planning, passenger information displays, and other transportation-related applications.
Hospitality: In the hospitality industry, the VFACE-19 can be used for digital menus, self-service kiosks, room booking systems, and other guest services to enhance the customer experience.
Education: The VFACE-19 can be used in educational settings for interactive learning activities, digital whiteboards, student information systems, and other educational applications.
Overall, the VFACE-19 is a versatile panel PC that can be customized to meet the specific requirements of various industries and applications, making it a valuable tool for businesses looking for a reliable and high-performance computing solution.
