SKU | TPRO-17 |
Screen Size | 17" |
Resolution | 1280 * 1024 |
Viewing Angle | 85/85/80/80 |
Brightness | 250 cd/㎡ |
Contrast Ratio | 1000:1 |
Touch Screen | Capacitive or Resistive |
Controller | USB interface |
Durability | Capacitive: ≥5M times / Resistive: ≥100,000 times |
Processor | Intel® Processors |
Memory | 4G/8G/16G |
Storage | under 5th Gen.: 1 * mSATA/1 *SATA(2 .5”Mechanical hard disk capacity ≤2TB) up to 6th Gen.: 1 * M.2/1 *SATA(2 .5” Mechanical hard disk capacity ≤2TB） |
Network | 2 *RTL8111 |
COM | 2 *RS232 (COM2 optional RS485) expansion to 5COM) |
USB | 4*USB |
Display | 1 *HDMI, 1 *VGA |
Expansion | 1 * M.2(KEY EWifi&BT 2230)/1 * M.2(KEY B 4G/5G LTE 3052) |
Operating System | Windows / Linux |
Dimensions (mm) | 401.6 *338.2 *58. 6 |
Mounting Hole Size (mm) | External embedded: 394 *324 Internal embedded: 383 .8 *320. 8 |
Gross weight (kg) | 5.65kg |
Installation methods | Embedded / Wall mount / Desktop |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
Power Input | 1*12VDC (6A) (Option 9~36VDC Wide-range Power Input) |
Packaging Information | 1 *Master, 1 *Adapter, 1* Power Supply Cable |
>Advantages:
The most advantages of the 17” Industrial Computer TPRO-17 include:
Rugged design: The TPRO-17 is built to withstand harsh industrial environments, making it durable and reliable for use in challenging conditions.
High performance: Equipped with a powerful processor and ample storage space, the TPRO-17 offers fast and efficient performance for industrial applications.
Versatile connectivity: The TPRO-17 features a variety of connectivity options, including USB ports, LAN ports, and serial ports, allowing for easy integration with other devices and systems.
Compact size: Despite its rugged design, the TPRO-17 has a compact size that makes it easy to install in tight spaces or mount on machinery or equipment.
Customization options: The TPRO-17 can be customized to meet specific industrial requirements, such as adding additional features or connectivity options.
Long-term reliability: The TPRO-17 is designed for long-term use in industrial settings, with components that are built to last and provide consistent performance over time.
Overall, the TPRO-17 offers a combination of durability, performance, and versatility that makes it well-suited for a wide range of industrial applications.
>Applications:
The 17” Industrial Computer TPRO-17 is suitable for a variety of industrial applications, including:
Manufacturing: The TPRO-17 can be used in manufacturing environments for process control, monitoring production lines, and managing inventory.
Automation: It is ideal for automation systems, such as robotics, conveyor systems, and industrial machinery control.
Transportation: The TPRO-17 can be used in transportation applications, such as vehicle monitoring, fleet management, and traffic control systems.
Energy and utilities: It is suitable for monitoring and controlling power plants, water treatment facilities, and other utility systems.
Oil and gas: The TPRO-17 can be used in oil and gas exploration, production, and refining operations for monitoring and control purposes.
Mining: It is suitable for mining operations for monitoring equipment, managing production, and ensuring safety protocols.
Food and beverage: The TPRO-17 can be used in food processing plants for monitoring production lines, managing inventory, and ensuring quality control.
Pharmaceutical: It is ideal for pharmaceutical manufacturing facilities for process control, monitoring equipment, and managing production data.
Overall, the TPRO-17 is a versatile industrial computer that can be used in a wide range of applications where durability, performance, and reliability are essential.
