UNO
VINCANWO GROUP
| Availability: | |
|---|---|
| Quantity: | |
| Model | UNO | ||||||||
| Primary Components | Processor Family | Intel Processors | |||||||
| Processor Model | 8th/6th|i5/i7,J1900,N95,N97,N100 | ||||||||
| Memory Type | DDR3, DDR4 | ||||||||
| Memory Support | 4GB, 8GB, 16GB | ||||||||
| Storage Type | 1x MSATA | 1x M.2 SATA | ||||||||
| Storage Support | MS:128GB~512GB | M.2: 128GB~1TB | ||||||||
| Operating Systems | Windows | Windows 10 IoT, Windows 10 Pro, Windows 11 Pro | |||||||
| Linux | Linux Ubuntu 20.04 or above (Contact your sales rep for more information) | ||||||||
| Peripherals & Wireless Connectivity | WiFi | Optional 802.11 a/b/g/n/ac/ax Wi-Fi 6 | |||||||
| Bluetooth | Optional Bluetooth 5.3 | ||||||||
| External I/O Ports | USB | 4x USB3.0, 4x USB2.0 | |||||||
| Serial/COM | 4x RS232, option RS485 | ||||||||
| Ethernet / LAN | 2x RJ45 2.5 GbE LAN | ||||||||
| Video Outputs | 1x HDMI, 1x DP | ||||||||
| Other Ports | 1x VGA, 1x GPIO option | ||||||||
| Power Input Port | DC-in Jack (Phoenix Type) | ||||||||
| Expansion Slots | Others | 1x M.2 (KEY E WiFi&BT 2230) 1x M.2 (KEY B 4G/5G LTE 3052) 4G module Single-layer I/O option | |||||||
| Power | Standard Power Adapter | 12~19V DC | |||||||
| Input Voltage Range | / | ||||||||
| Weight / Dimensions | Weight | 1.10 kg | |||||||
| Dimensions | 165x125x59.1 mm | ||||||||
| Thermal & Environmental | Operating Temperature | -30°C ~ 70°C | |||||||
| Storage Temperature | -40°C ~ 80°C | ||||||||
| Cooling Solution | Passive – Fanless, Fan | ||||||||
| Humidity Range | 10% – 95% Non-condensing | ||||||||
| Enclosure | Material | Aluminum | |||||||
| Color | Black | ||||||||
| Led Indicator Light | HDD Access, Power | ||||||||
| Mounting Options | DIN Rail Mount, Wall Mount, Desktop | ||||||||
Vincanwo Group’s UNO ultra-compact DIN-rail fanless NUC mini PC combines NUC-like small form factor with industrial DIN-rail ruggedness, delivering space savings, 24/7 reliability in harsh environments, and flexible edge/IoT/automation deployment. Below are its key benefits, aligned with Vincanwo Group’s industrial PC portfolio and typical UNO-series specs.
| Benefit | Why It Matters | Use Case Fit |
|---|---|---|
| Ultra-compact DIN-rail mount (NUC-sized) | Minimal cabinet footprint; neat alignment with PLCs, drives, switches | Dense control cabinets, edge nodes, small automation cells |
| Fanless passive cooling (sealed alloy chassis) | No moving parts → higher MTBF, less dust ingress, silent operation | High-dust, vibration-prone, noise-sensitive industrial sites |
| Industrial-grade durability | Wide temp range (-20°C to +60°C typical), shock/vibration resistance, wide DC input (12–24V/9–36V) | Factory floors, outdoor cabinets, transportation edge |
| Rich I/O & expandability | GigE LAN, USB 3.x, COM (RS232/485), M.2/mini-PCIe for WiFi/4G/5G/NVMe | IoT gateways, edge analytics, machine vision, protocol conversion |
| ⚙️ Scalable compute (Intel-based) | Celeron for data logging/gateways; Core i3/i5 for edge AI/vision | Tiered workloads from basic to mid-range inference |
| Multi-OS & global compliance | Windows 10 IoT, Linux (Ubuntu/Debian); CE/FCC/RoHS, multi-region plugs | International deployments, regulated industries, legacy/modern stacks |
| ️ Customizable & serviceable | BOM tuning, private mold, 1-year warranty, tech support | OEM/ODM projects, mission-critical edge fleets |
Space & Installation Efficiency: DIN-rail mounting eliminates shelf space and simplifies cable routing, ideal for retrofits or dense cabinets. NUC-sized form factor (~100×100×50 mm class) fits tight spots where traditional desktops/servers can’t.
Reliability & Low Maintenance: Fanless design removes fan bearings as a failure point, prevents dust accumulation, and reduces service costs. Passive heatsinks efficiently dissipate heat in industrial temp ranges, enabling 24/7 unattended operation.
Performance & Versatility: Scalable CPU options match compute to workload—from basic Modbus/MQTT data logging to edge AI/vision defect detection. Rich I/O enables direct connection to sensors, cameras, and cloud backends.
Deployment Agility: Supports wired (GigE) and wireless (WiFi/4G/5G via M.2/mini-PCIe) connectivity for remote sites. Multi-OS compatibility adapts to legacy and modern software stacks.
Total Cost of Ownership (TCO): Lower upfront footprint, reduced maintenance, and longer lifespan offset initial investment—critical for large-scale edge deployments.
CPU: Intel Celeron N/J-series or Core i3/i5 (select models)
Memory: Up to 16GB DDR4 SODIMM
Storage: M.2 NVMe/SATA SSD (2280), optional 2.5" SATA (if applicable)
I/O: 2–4×GigE LAN, 4×USB 3.x, 2–4×COM (RS232/485), HDMI/VGA (dual display)
Power: 12–24V DC (industrial standard), optional 9–36V wide input; redundant PSU available
OS: Windows 10 IoT Enterprise, Linux (Ubuntu/Debian), Android (RK3566-based models)
Industrial Automation: PLC/HMI co-processing, motion control, recipe management, 24/7 supervision.
IoT Gateway: Sensor data collection, protocol conversion (Modbus/MQTT/OPC UA), edge filtering/upload to cloud.
Edge Computing: Real-time analytics, predictive maintenance, AI inference (e.g., defect detection, quality control).
Network Security: Compact firewall, VPN concentrator, traffic inspection in distributed sites.
Right-size the CPU: Use Celeron for data logging/gateways; Core i3/i5 for vision/AI inference.
Secure storage: Use TPM 2.0 (if available) and encrypted SSDs for sensitive data.
Thermal management: Ensure adequate cabinet airflow; use DIN-rail heatsink extensions for high-TDP CPUs.
Remote management: Enable WOL, PXE, or iAMT (if supported) for remote deployment/updates.
