2U Rackmout Chassis
VINCANWO GROUP
| Availability: | |
|---|---|
| Quantity: | |
| SKU | 2U Rackmount Chassis | |||||
Material | High strength galvanized steel sheet (black) | |||||
Front button/interface | Front switch , LED hard drive indicator light , LED system indicator light , reset switch | |||||
motherboard | Compatible with Micro ATX motherboards and standard ATX motherboards | |||||
Processor | Support LGA1155 3th Intel® Core ™ i3/i5/i7/ Pentium/Celeron | Support LGA1150 4th Intel® Core ™ i3/i5/i7/ Pentium/Celeron | Support Intel LGA1151 6/7/8/9th i3/i5/i7/i9/ Pentium/Celeron | Support Intel LGA1200 10/11th i3/i5/i7/i9/ Pentium/Celeron | Support Intel LGA1700 12/ 13/ 14th i3/i5/i7/i9/ Pentium/Celeron | Haiguang 3350 octacore 3.0GHz |
Chipsetchipset | B75 | H87 | H310 | H570 | H670 | / |
Memory | 2 * DDR3 supports a maximum of 16GB | 4 * DDR3 supports up to 32GB | 2 * DDR4 supports a maximum of 64GMaximum support 32GB | 4 * DDR4 supports up to 128GB | 2 * DDR4 supports a maximum of 64G | PC-DDR4 supports a maximum of 64G |
Storage | 2*SATA 2 .0 | 6*SATA 3.0 | 3*SATA 3.0 , 1* M .2 NVME | 4*SATA 3.0(Support RAID 0/1/5/10) 1* MSATA 1* M .2 | 3*SATA 3.0 , 1* M .2 NVME | 1 * M .2 NVME protocol , 4 * SATA 3.0 |
Ethernet LAN | 2 * Gigabit I210 | 2 * Gigabit 82583V | 1 * Gigabit I219V, 1 * 2 .5 Gigabit I226 | 2 * 2 .5 Gigabit I226V | 1 * Gigabit I219V, 1 * 2 .5 Gigabit I226 | 1 * RLT8111 Gigabit Ethernet card , supports Wake on LAN and PCIe functionality |
COM | Rear mounted 2 * RS232(Supports RS422/485)Scalable 4 * RS232 | Rear mounted 2 * RS232Scalable 8 * RS232(COM3 supports RS232/422/485) | Rear mounted 2 * RS232Scalable 4 * RS232 (COM3/4 can support RS422/485) | Rear mounted 2 * RS232 (COM1/2 can support RS422/485)Scalable 4 * RS232 | Rear mounted 2 * RS232 (COM1/2 can support RS485)Scalable 4 * RS232 | 1* RS232 |
USB | Front end 2 * USB 2 .0 Rear 4 * USB 3.0 | Front end 2 * USB 2 . 0Rear 2 * USB 3 . 0, 2 * USB 2 .0 | Front end 2 * USB 2 .0Rear 4 * USB 3.2 * USB 2 .0 | Front end 2 * USB 2 . 0Rear 4 * USB 3 . 0, 2 * USB 2 .0 | Front end 2 * USB 2 .0 Rear 8 * USB 3.2 | Front USB 2 .0 Rear USB 3.0 |
Video Output | 1*VGA , 1* HDMI | 2*VGA , 1* HDMI | 1*VGA , 1* DVI-I , 1* HDMI 1 .4 | 1*VGA , 1* HDMI 1 .4 | 1*VGA , 1* HDMI 2 .0 | No integrated display |
PS interface | 1* PS2 | 1* PS2 | 1* PS2 | 1* PS2 | / | / |
Expansion Slots |
1* PCI-E X16 1* PCI-E X4 2* PCI 1* MiniPCI-E |
1* PCI-E X16 1* PCI-E X4 1* PCI-E X1 4* PCI |
1* PCI-E X16 1* PCI-E X4 2* PCI |
1* PCI-E X16 3*PCI-E X4 1* PCI-E X1 2* PCI |
2* PCI-E X16 3*PCI-E X4 | 1 * PCI-E X16_ 1 interface , capable of connecting independent graphics cards (PCI-E is X8 signal) 1 * PCI-E X16_2 interface , capable of connecting independent graphics cards (PCI-E is X4 signal) 1 * PCI-E X8 interface1 * PCI-E X1 interface |
LPT parallel port | Scalable | |||||
Audio Output |
Mic in , Line in;Line out |
Mic in , Line out | Integrated Realtek ALC4080 HD Digital Audio Decoder 1 * LINE - IN 1 * LINE-OUT1 * MIC_ IN | |||
Operating System | Windows Windows XP/7/8/10 , Linux | Windows 7\8\10 , LINUX | Windows 7\8\10 , LINUX (Determined by CPU algebra) | Windows 10/11 , Linux | Windows 10/11 , Linux | Support Kylin/iOS/Windows 10 (adaptation required) |
Dimension | 482*400*88 .5mm | |||||
Gross weight | 12.72kg | |||||
Installation method | Shelf style/desktop style | |||||
Operation temperature | -30℃ ~ 70℃ | -20℃ ~ 60℃ | ||||
Storage temperature | - 40℃ ~ 80℃ | |||||
Relative humidity | 10% - 90%(*Non-condensation) | |||||
>Advantages:
There are the most advantages to using a 2U rack mount chassis for housing electronic components in a data center or server room:
1. Space-saving: A 2U chassis allows you to mount multiple components in a compact and efficient manner, saving valuable rack space in a data center or server room.
2. Scalability: 2U chassis can accommodate a variety of components, such as servers, storage devices, and networking equipment, making it easy to scale and expand your infrastructure as needed.
3. Cooling and ventilation: Many 2U chassis come equipped with cooling fans and ventilation options to help regulate the temperature of the components and prevent overheating.
4. Cable management: 2U chassis often include features for organizing and managing cables, such as cable routing options and cable management bars, to help maintain a clean and organized setup.
5. Security: Rack mount chassis provide physical protection for electronic components, helping to prevent damage and unauthorized access.
6. Accessibility: Front-accessible drive bays and other features make it easy to access and service components within the chassis without having to remove it from the rack.
Overall, a 2U rack mount chassis offers a versatile and practical solution for organizing and protecting electronic components in a rack-mounted configuration.
>Applications:
2U rack mount chassis are commonly used in a variety of applications where space-saving, organization, and protection of electronic components are important. The most common applications of 2U rack mount chassis include:
1. Data centers: 2U rack mount chassis are often used in data centers to house servers, storage devices, and networking equipment in a compact and organized manner.
2. Telecommunications: 2U chassis are commonly used in telecommunications infrastructure to house networking equipment, such as routers, switches, and modems.
3. Broadcast and media: 2U rack mount chassis are used in broadcast and media production environments to house video servers, audio equipment, and other broadcasting hardware.
4. Industrial automation: 2U chassis are used in industrial automation applications to house control systems, PLCs, and other industrial computing equipment.
5. Medical equipment: 2U rack mount chassis are used in medical equipment applications to house diagnostic equipment, imaging systems, and other medical devices.
6. Military and aerospace: 2U chassis are used in military and aerospace applications to house communication systems, radar equipment, and other mission-critical hardware.
Overall, 2U rack mount chassis are versatile and widely used in a variety of industries and applications where space-saving, organization, and protection of electronic components are essential.
