SKU | TPRO-19 |
Screen Size | 19inch |
Resolution | 1280 * 1024 |
Viewing Angle | 85/85/80/80 |
Brightness | 250 cd/㎡ |
Contrast Ratio | 1000:1 |
Touch Screen | Capacitive or Resistive |
Controller | USB interface |
Durability | Capacitive: ≥5M times / Resistive: ≥100,000 times |
Processor | Intel® Processors |
Memory | 4G/8G/16G |
Storage | under 5th Gen.: 1 * mSATA/1 *SATA (2 .5” Mechanical hard disk capacity ≤2TB) up to 6th Gen.: 1 * M.2/1 *SATA (2 .5” Mechanical hard disk capacity ≤2TB） |
Network | 2 *RTL8111 |
COM | 2 *RS232 (COM2 optional RS485) expansion to 5COM) |
USB | 4*USB |
Display | 1 *HDMI, 1 *VGA |
Expansion | 1 * M.2(KEY EWifi&BT 2230)/1 * M.2(KEY B 4G/5G LTE 3052) |
Operating System | Windows / Linux |
Dimensions (mm) | 445 *374.8 *58. 6 |
Mounting Hole Size (mm) | External embedded: 439 *359 Internal embedded: 423 .8 *353. 8 |
Gross weight (kg) | 5.70kg |
Installation methods | Embedded / Wall mount / Desktop |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
Power Input | 1*12VDC (6A) (Option 9~36VDC Wide-range Power Input) |
Packaging Information | 1 *Master, 1 *Adapter, 1* Power Supply Cable |
>Advantages:
The most common advantages of the 19” Embedded Industrial Computer TPRO-19 include:
Rugged and durable design: The TPRO-19 is built to withstand harsh industrial environments, with a sturdy metal chassis that can handle vibrations, shocks, and extreme temperatures.
High-performance computing: The TPRO-19 is equipped with powerful hardware components, such as a high-resolution display and fast processors, making it suitable for demanding industrial applications that require high computing power.
Versatile connectivity options: The TPRO-19 offers a range of connectivity options, including USB, Ethernet, and serial ports, allowing for easy integration with other devices and systems.
Compact and space-saving: Despite its robust design, the TPRO-19 is compact and can be easily mounted in tight spaces, making it ideal for industrial environments where space is limited.
Easy integration: The TPRO-19 can be easily integrated into existing systems or used as a standalone device, thanks to its versatile mounting options and compatibility with various industrial protocols.
Overall, the TPRO-19 offers a reliable and high-performance solution for industrial computing needs, with its rugged design, powerful hardware, and versatile connectivity options.
>Applications:
The 19” Embedded Industrial Computer TPRO-19 is suitable for a wide range of industrial applications, including:
Manufacturing: The TPRO-19 can be used in manufacturing environments for process control, monitoring production lines, and managing inventory.
Automation: It is ideal for automation applications, such as controlling robotic systems, monitoring sensors, and managing industrial machinery.
Transportation: The TPRO-19 can be used in transportation systems for tracking vehicles, managing logistics, and monitoring traffic flow.
Energy and utilities: It is suitable for monitoring and controlling energy production and distribution systems, such as power plants, renewable energy installations, and smart grids.
Oil and gas: The TPRO-19 can be used in the oil and gas industry for monitoring drilling operations, managing pipelines, and controlling production facilities.
Aerospace and defense: It is suitable for aerospace and defense applications, such as monitoring aircraft systems, controlling drones, and managing military equipment.
Overall, the TPRO-19 is a versatile industrial computer that can be used in various applications where reliability, durability, and high performance are essential.
