18.5” High-performance Industrial Computer | VFACEH-185
VINCANWO GROUP
Availability: | |
---|---|
Quantity: | |
SKU | VFACEH-185 |
Screen Size | 18.5” |
Resolution | 1920x1080 |
Viewing Angle | 89/89/89/89 |
Brightness | 250 cd/㎡ |
Contrast Ratio | 1000:1 |
Touchscreen | Capacitive, Resistive |
Controller | USB interface |
Durability | Capacitive: ≥ 5M times, Resistive: : ≥ 100,000 times |
Chipset | H310 (LGA1151), H610 (LGA1700) |
Memory Type | 2x DDR4 4G, 8G, 16G, 32G |
Storage Type | 1x M.2 Slot, support M.2 2260/2280 |
Ethernet / LAN | 2x RTL8111 |
Serial / Com | 2x RS232 (COM2 option RS485) |
USB | Front 1x USB, Rear 4x USB |
Video Outputs | 1x HDMI, 1x VGA |
Expansion Slots | 1xMini-PC IE WiFi, 1x Mini PCIE WiFi & Bluetooth or 4G LTE |
Operating Systems | Windows, Linux |
Dimension | 476.4x339.3x70.3mm |
Mounting Hole Size | 464x327mm |
Gross Weight | 6 .54kg |
Mounting Options | Embedded, Wall Mount, Desktop Stand |
Operating Temperature | -30℃ ~ +70℃ |
Storage Temperature | -40℃ ~ +80℃ |
Humidity Rage Non-condensing | 5% - 95% |
Power | Input Voltage Range 9 – 36V DC Standard Power: Optional 12V AC/DC Adapter: 5A, 60W |
>Advantages:
There are several advantages of the 18.5” High-performance Industrial Computer | VFACEH-185:
Large Display: The 18.5” display provides ample screen real estate for running multiple applications simultaneously, making it easier to multitask and view data and information at a glance.
High Performance: The VFACEH-185 is equipped with a high-performance processor and ample RAM, allowing it to handle demanding industrial applications with ease. This ensures smooth and efficient operation even with resource-intensive software.
Rugged Design: The industrial-grade design of the VFACEH-185 makes it durable and reliable in harsh industrial environments. It can withstand temperature fluctuations, dust, vibrations, and other challenges commonly found in industrial settings.
Connectivity Options: The VFACEH-185 features a variety of connectivity options, including multiple USB ports, Ethernet, and serial ports. This allows for easy integration into existing industrial systems and peripherals.
Wide Operating Temperature Range: The VFACEH-185 is designed to operate within a wide temperature range, making it suitable for use in environments with extreme temperatures.
Versatility: The VFACEH-185 is a versatile industrial computer that can be used in a wide range of industrial applications, including manufacturing, automation, control systems, and more.
Overall, the VFACEH-185 offers a combination of performance, durability, and versatility that makes it an ideal choice for demanding industrial environments.
>Applications:
The 18.5” High-performance Industrial Computer | VFACEH-185 is well-suited for a variety of industrial applications, including:
Manufacturing: The VFACEH-185 can be used in manufacturing environments for process monitoring, quality control, inventory management, and production scheduling.
Automation: This industrial computer is ideal for automation applications, such as controlling robotic systems, monitoring sensors and actuators, and managing production lines.
Control Systems: The VFACEH-185 can be used in control systems for managing and monitoring industrial equipment, such as pumps, motors, valves, and other machinery.
Data Acquisition: This industrial computer can be used for data acquisition applications, such as collecting and analyzing data from sensors, meters, and other devices in industrial settings.
SCADA Systems: The VFACEH-185 is suitable for SCADA (Supervisory Control and Data Acquisition) systems used for monitoring and controlling industrial processes and equipment.
HMI (Human Machine Interface): The VFACEH-185 can serve as a user-friendly HMI for operators to interact with and control industrial machinery and systems.
Industrial IoT (Internet of Things): This industrial computer can be integrated into Industrial IoT systems for collecting, analyzing, and transmitting data from connected devices in industrial environments.
Overall, the VFACEH-185 is a versatile industrial computer that can be used in a wide range of applications to improve efficiency, productivity, and control in industrial settings.
Transportation and Fleet Management:
Used in vehicles and transportation hubs for monitoring, navigation, and communication.
Other Applications:
A blog post by AOPEN notes that they are also used in various industries for tasks like data logging, remote access, and more.
