SKU | VFACEH-173 |
Screen Size | 17.3” |
Resolution | 1920x1080 |
Viewing Angle | 80/80/60/80 |
Brightness | 400 cd/㎡ |
Contrast Ratio | 600:1 |
Touchscreen | Capacitive, Resistive |
Controller | USB interface |
Durability | Capacitive: ≥ 5M times, Resistive: : ≥ 100,000 times |
Chipset | H310 (LGA1151), H610 (LGA1700) |
Memory Type | 2x DDR4 4G, 8G, 16G, 32G |
Storage Type | 1x M.2 Slot, support M.2 2260/2280 |
Ethernet / LAN | 2x RTL8111 |
Serial / Com | 2x RS232 (COM2 option RS485) |
USB | Front 1x USB, Rear 4x USB |
Video Outputs | 1x HDMI, 1x VGA |
Expansion Slots | 1xMini-PCIE WiFi, 1x Mini PCIE WiFi & Bluetooth or 4G LTE |
Operating Systems | Windows, Linux |
Dimension | 446.2x296.2x73.1mm |
Mounting Hole Size | 432x285mm |
Gross Weight | 5.68kg |
Mounting Options | Embedded, Wall Mount, Desktop Stand |
Operating Temperature | -30℃ ~ +70℃ |
Storage Temperature | -40℃ ~ +80℃ |
Humidity Rage Non-condensing | 5% - 95% |
Power | Input Voltage Range 9 – 36V DC Standard Power: Optional 12V AC/DC Adapter: 5A, 60W |
>Advantages:
The advantages of the 17.3” High-performance Industrial Computer | VFACEH-173 include:
High-performance computing: The VFACEH-173 is equipped with a powerful processor that provides high-speed computing capabilities, making it suitable for demanding industrial applications that require fast data processing.
Large display: The 17.3” high-resolution display of the VFACEH-173 offers a large viewing area, making it easier to work with detailed graphics and data. This is especially beneficial for applications that require visual monitoring or analysis.
Rugged and reliable design: The VFACEH-173 is built to withstand harsh industrial environments, with a rugged design that can withstand dust, moisture, and temperature fluctuations. This ensures reliable operation even in challenging conditions.
Multiple connectivity options: The VFACEH-173 offers multiple connectivity options, including USB, Ethernet, and serial ports, making it easy to integrate with existing industrial systems and peripherals.
Customizable configurations: The VFACEH-173 can be customized to meet specific application requirements, with options for additional memory, storage, and expansion slots. This flexibility allows users to tailor the computer to their specific needs.
Overall, the VFACEH-173 offers high performance, durability, and flexibility, making it an ideal choice for industrial applications that require reliable computing power in challenging environments.
>Applications:
The 17.3” High-performance Industrial Computer | VFACEH-173 is versatile and well-suited for a wide range of industrial applications. The most common applications include:
Industrial automation: The VFACEH-173 can be used for controlling and monitoring automated industrial processes, such as assembly lines, robotic systems, and manufacturing equipment.
Data acquisition and analysis: The high-performance computing capabilities of the VFACEH-173 make it ideal for applications that require real-time data acquisition, processing, and analysis, such as quality control, testing, and monitoring systems.
HMI (Human Machine Interface): The large display and powerful processor of the VFACEH-173 make it suitable for use as a human-machine interface in industrial control systems, allowing operators to interact with and control machinery and equipment.
SCADA (Supervisory Control and Data Acquisition): The VFACEH-173 can be used in SCADA systems to monitor and control industrial processes and equipment, providing real-time data visualization and control capabilities.
Transportation and logistics: The rugged design of the VFACEH-173 makes it suitable for use in transportation and logistics applications, such as fleet management, vehicle tracking, and warehouse management systems.
Oil and gas industry: The VFACEH-173 can be used in the oil and gas industry for monitoring and controlling drilling operations, pipeline systems, and other critical infrastructure.
Overall, the VFACEH-173 is a versatile industrial computer that can be used in a wide range of applications that require high-performance computing, durability, and reliability in challenging industrial environments.
