| SKU | OPX-15 |
| Screen Size | 15" |
| Resolution | 1024*768 |
| Viewing Angle | 89/89/89/89 |
| Brightness | 350 cd/m2 |
| Contrast Ratio | 1000:1 |
| Touch Screen | Capacitive |
| Controller | USB interface |
| Durability | ≥ 5M times |
| USB | 1 *USB (For touchscreen cable) |
| Display | 1 *HDMI, 1 *VGA |
| Dimensions (mm) | 358.4*286.7*49.5mm |
| Mounting Hole Sizes (mm) | 349.4*277.2mm |
Individual Gross Weight (KG) | 3.70kg |
| Mounting Options | Embedded / Wall-mounted / Desktop |
| Operating Temperature | -30 ~ +70℃ |
| Storage Temperature | -40 ~ +80℃ |
Storage Humidity *Non-condensing | 5% ~ 95% |
| Power Input | 12V DC (3A) <Option Wide-range 9 ~ 36V DC Power Input> |
| Packaging Information | 1 *Master, 1 *Adapter, 1* Power Supply Cable, 1 *Touch Screen Cable, 1 *VGA cable, 1 *Manual, 1 *Warranty Card |
| Feature | OPX-15 Specifications |
|---|---|
| Display | 15" TFT LCD (IPS/PLS panel) |
| Resolution | 1920×1080 (FHD) |
| Brightness | 400–800 cd/m²(auto-dimming to 1 cd/m²) |
| Power Consumption | <15W typical (idle: 3W, peak: 25W) |
| Touch Technology | Projected Capacitive (P-CAP) with <0.5Wstandby |
| Operating Temp | -30°C to +70°C (fanless) |
| Ingress Protection | IP65 front / IP54 rear |
| Power Input | 24V DC (9–36V) or PoE+ (802.3at) |
| Eco-Certifications | ENERGY STAR 8.0, TCO Certified 9.0, EPEAT Gold |
Adaptive Brightness
Ambient Light Sensor: Auto-adjusts brightness (0.1–800 nits) based on lux levels
Schedule-Based Dimming: Reduces to 5% brightness during non-operational hours
Low-Power Components
Panel: IGZO (Indium Gallium Zinc Oxide) LCD for 40% lower backlight power vs. a-Si
LED Backlight: 500,000-hour lifespan (70% brightness retention at 100k hours)
Power Management
Deep Sleep Mode: <0.5W consumption during inactivity
PoE+ Support: Single-cable power/data (saves 20% vs. traditional AC wiring)
| Interface | Automation Use Case |
|---|---|
| Fieldbus | PROFINET, EtherCAT via OPC UA gateway |
| I/O | 4× isolated GPIO (24V@100mA), RS-485 (2.5kV) |
| Video/Data | HDMI 2.0, USB-C w/ DP Alt Mode, GbE w/ TSN |
| Expansion | OPS slot (Intel Atom x7000E compute module) |
| Parameter | OPX-15 Advantage |
|---|---|
| Power per Nit | 0.03W/nit (vs. 0.08W/nit in standard displays) |
| Heat Dissipation | Passive cooling only (no fans → dust immunity) |
| Material Efficiency | 30% recycled aluminum chassis |
| TCO Reduction | $240/year saved (vs. 300-nit legacy HMI @24/7 ops) |
Solar-Powered Sites: Off-grid substations, weather stations
LEED-Certified Factories: Sustainable manufacturing lines
Battery-Operated AGVs: AMR control panels
ISO 50001 Facilities: Energy management dashboards
Power Optimization
Use PoE++ switches (802.3bt) to power display + peripherals (e.g., barcode scanners)
Enable "Eco Mode" scheduling in SCADA/HMI software (e.g., Ignition Edge)
Thermal Management
In high-temp environments (>60°C), apply phase-change thermal pads (e.g., Laird Tflex 700)
Sunlight Readability
Pair with optical bonding (optional): Boosts contrast 3× while reducing brightness needs by 35%
Recycling Compliance
Leverage take-back programs (e.g., Siemens ECO Recycling) for RoHS-compliant disposal
| Metric | Legacy 15" HMI | OPX-15 | Savings |
|---|---|---|---|
| Annual Power Use | 175 kWh (300 nits) | 65 kWh(adaptive) | 63% reduction |
| CO₂ Emissions | 78 kg/year | 29 kg/year | 62% reduction |
| Backlight Replacement | Every 3–5 years | Lifetime(10+ years) | $200/unit saved |
