SKU | X15T |
| Screen Size | 15.6" |
Dimension (mm) | 407x305.8x45.5 |
Weight (g) | 3300 |
Device Color | Black |
LCD | 15.6'' FHD 16:9, 1920*1080,750nits |
Touch Panel | Optional 10 point capacitive, G+G |
Camera | Front 2.0MP |
Performance Parameter | Intel i5-1135G7/I7-1165G7 CPU OS: Windows 11/10 RAM: 16GB ROM: 256GB/512GB/1TB |
I/O | SD Card x 1, SIM Card x 1 USB2.0 x 1, USB3.0 x 3, HDMI x 1 DB9 (RS232) x 1, RJ45 x 2 Φ3.5mm standard earphone jack x 1 POGO 5pin x 1, DC 19V 3.42A Power connector x 1 Passenger transfer card PCIE X4 solt or HDD x 1 (Optional) Anti theft lock hole x 1, Heat dissipation air outlet (right) x 1 |
Power | AC100V ~ 240V, 50Hz/60Hz, DC 19V/3.42A |
Capacity | 7.4V/1750mAh+7.4V/6300mAh |
Type | Double Lithium-ion polymer battery |
Endurance | 8.5hrs (EM-X15U), 7+0.5hrs (EM-X15T) |
GNSS | Support GPS, Optional GPS+Beidou |
WiFi | 2.4G+5.8G, WIFI 802.11(a/b/g/n/ac) (EM-X15U) WiFi 6, 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax (EM-X15T) |
Bluetooth | BT 4.2, BT 5.1 Transmission distance: 10m |
2G/3G/4G/5G (Optional) | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD: B40, WCDMA: B1/B2/B5/B8, GSM: B2/B3/B5/B8 EM-X15T LTE-FDD B1/3/5/7/8/20 ，LTE-TDD B40 WCDMA B1/5/8，GSM 900/1800 5G NR: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/ n38/n40/n41/n48*/ n66/n71/n77/n78/n79, LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/ B19/B20/B25/B26/B28/B29/B30/B32/B66/B71, LTE-TDD: B34/B38/B39/B40/B41/B42/B43/B48, LAA: B46, WCDMA: B1/B2/B3/B4/B5/B6/B8/B19 |
NFC | Optional, 13.56MHz, Support ISO/IEC 14443A/B/15693/18092/mifare protocols Card reading distance: 4cm |
Fingerprint | SPI fingerprint (Power on login) |
IP Grade | IP65 |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
>Advantages:
The X15T rugged notebook/laptop offers the most advantages for users in demanding environments:
Durability: The X15T is built to withstand harsh conditions, including drops, shocks, vibrations, and extreme temperatures. Its ruggedized chassis and shock-resistant design ensure that it can handle rough handling without compromising performance.
Reliability: With a high-performance processor and ample storage space, the X15T delivers reliable performance even in challenging situations. You can trust that your data and applications will be secure and accessible when you need them.
Full HD Display: The X15T features a 15.6” full HD display, providing crisp and clear visuals for work or entertainment. Whether you're viewing detailed images, watching videos, or working on spreadsheets, the high-resolution display enhances your viewing experience.
Portability: Despite its rugged design, the X15T is still portable and easy to carry around. Its 15.6” size strikes a balance between screen real estate and portability, making it suitable for on-the-go use in various environments.
Connectivity: The X15T comes equipped with a range of connectivity options, including USB ports, HDMI, Ethernet, and more. This allows you to easily connect to peripherals, networks, and external displays, enhancing your productivity and versatility.
Overall, the X15T rugged notebook/laptop offers a combination of durability, reliability, performance, and connectivity, making it an ideal choice for users who require a rugged computing solution in challenging environments.
>Applications:
The 15.6” Rugged Notebook/Laptop X15T is designed for use in a variety of demanding environments where standard laptops may not be able to withstand the conditions. The most common applications of the X15T include:
Field Work: The rugged design of the X15T makes it ideal for fieldwork in industries such as construction, agriculture, forestry, and oil and gas. It can withstand drops, shocks, and vibrations, making it suitable for use in outdoor and rugged environments.
Military and Defense: The X15T is often used in military and defense applications where durability and reliability are crucial. It can withstand harsh conditions, extreme temperatures, and rough handling, making it suitable for use in combat zones and other challenging environments.
Industrial Settings: The X15T is commonly used in industrial settings such as manufacturing plants, warehouses, and production facilities. Its rugged design allows it to withstand dust, dirt, moisture, and other hazards commonly found in industrial environments.
Emergency Services: The X15T is used by emergency services personnel such as firefighters, paramedics, and law enforcement officers. Its rugged design ensures that it can withstand the rigors of emergency response situations and remain operational when needed most.
Outdoor Recreation: The X15T is also popular among outdoor enthusiasts, such as hikers, campers, and adventurers. Its rugged design makes it suitable for use in outdoor activities where standard laptops may not be able to withstand the elements.
Overall, the X15T rugged notebook/laptop is versatile and well-suited for a wide range of applications in demanding environments where durability, reliability, and performance are essential.
