SKU | X14T |
| Screen Size | 14" |
Dimension (mm) | 363.2x287.4x42.1 |
Weight (g) | 2850 |
Device Color | Black |
LCD | 14” FHD 16:9, 1920*1080, 1000nits |
Touch Panel | Optional 10 points capacitive, G+G, Corning Gorilla Glass |
Camera | Front 2.0MP |
Performance Parameter | Intel Core™ i5-1135G7/I7-1165G7 CPU OS: Windows 11/10 RAM: 16GB ROM: 256GB/512GB/1TB |
I/O | SD Card x 1, SIM Card x 1 USB2.0 x 1, USB3.0 x 3, HDMI x 1 DB9 (RS232) x 1, RJ45 x 2 Φ3.5mm standard earphone jack x 1 POGO 5pin x 1, DC 19V 3.42A Power connector x 1 Passenger transfer card PCIE X4 solt or HDD x 1 (Optional) Anti theft lock hole x 1, Heat dissipation air outlet (right) x 1 |
Power | AC100V ~ 240V, 50Hz/60Hz, DC 19V/3.42A/65W |
Capacity | 7.4V/1750mAh+7.4V/6300mAh |
Type | Double Lithium-ion polymer battery |
Endurance | 8.5hrs+30min |
GNSS | Support GPS, Optional GPS+Beidou |
WiFi | WiFi 6, 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax |
Bluetooth | BT 5.1 Transmission distance: 10m |
2G/3G/4G/5G (Optional) | LTE-FDD B1/3/5/7/8/20，LTE-TDD B40， WCDMA B1/5/8，GSM 900/1800 5G NR n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/ n38/n40/n41/n48*/ n66/n71/n77/n78/n79 LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/ B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 LTE-TDD B34/B38/B39/B40/B41/B42/B43/B48 LAA B46，WCDMA B1/B2/B3/B4/B5/B6/B8/B19 |
NFC | Optional, 13.56MHz, Support ISO/IEC 14443A/B/15693/18092/mifare protocols Card reading distance: 4cm |
Fingerprint | SPI fingerprint (Power on login) |
IP Grade | IP65 |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
>Advantages:
The X14T 14” rugged notebook/laptop offers the most advantages:
Durability: The X14T is built to withstand harsh environments, including drops, spills, dust, and extreme temperatures. It meets military-grade standards for ruggedness, ensuring reliable performance in tough conditions.
Portability: Despite its rugged construction, the X14T is still lightweight and portable, making it easy to carry around for on-the-go work in various settings.
Performance: The X14T is equipped with a powerful Intel Core processor, providing fast and efficient performance for multitasking, productivity, and demanding applications.
Connectivity: The X14T features a range of connectivity options, including USB ports, HDMI, Ethernet, and more, allowing you to easily connect to peripherals and networks.
Security: The X14T offers advanced security features, such as biometric authentication, TPM 2.0, and optional smart card reader, to keep your data and device secure.
Long battery life: The X14T is designed for all-day use with a long-lasting battery, ensuring you can work without interruption even in remote locations.
Overall, the X14T rugged notebook/laptop is a reliable and versatile device that is well-suited for professionals working in challenging environments.
>Applications:
The X14T 14” rugged notebook/laptop is designed for a variety of applications in industries and environments where durability and reliability are essential. The most common applications of the X14T include:
Field work: The rugged construction of the X14T makes it ideal for fieldwork in industries such as construction, engineering, agriculture, and utilities. It can withstand drops, vibrations, and extreme temperatures, allowing professionals to work in challenging outdoor conditions.
Military and defense: The X14T meets military-grade standards for ruggedness, making it suitable for military and defense applications. It can be used in tactical operations, vehicle-mounted systems, and other mission-critical tasks.
Manufacturing and industrial settings: The X14T is well-suited for use in manufacturing plants, warehouses, and other industrial environments where dust, moisture, and rough handling are common. Its durability ensures reliable performance in these demanding settings.
Emergency services: The X14T is a reliable tool for emergency responders, firefighters, and law enforcement personnel who need a rugged device that can withstand the rigors of their work. It can be used in emergency situations, disaster response, and public safety operations.
Outdoor activities: The X14T is also suitable for outdoor enthusiasts, adventurers, and travelers who need a durable laptop for camping, hiking, boating, and other outdoor activities. Its rugged design ensures it can withstand the elements and rough handling.
Overall, the X14T rugged notebook/laptop is versatile and well-suited for a wide range of applications in industries and environments where durability, reliability, and performance are crucial.
