SKU | VFACE-156 |
Screen Size | 15.6inch |
Resolution | 1920*1080 |
Viewing Angle | 89/89/89/89 |
Brightness | 250 cd/m2 |
Contrast Ratio | 3000:1 |
Touch Screen | Capacitive, Resistive |
Controller | USB interface |
Durability | Capacitive: ≥5M times / Resistive: ≥100,000 times |
Processor | Intel® Processors |
RAM | 4G/8G/16G/32G |
SSD | under 5th Gen.: 1 * mSATA/1 *SATA(2 .5”Mechanical hard disk capacity ≤2TB) up to 6th Gen.: 1 * M.2/1 *SATA(2 .5” Mechanical hard disk capacity ≤2TB） |
Network | 1 *RTL8111 |
COM | 2 *RS232 (COM2 optional RS485) |
USB | 1* Front USB, 4* Rear USB |
Display | 1 *HDMI, 1 *VGA |
Expansion Slots | under 5th Gen.: 1 * Mini PCIE Wifi&BT or 4G LTE up to 6th Gen.: 1 * M.2(KEY EWifi&BT 2230)/1 * M.2(KEY B 4G/5G LTE 3052) |
Operating System | Windows / Linux |
Dimensions (mm) | 402.7*269.7*61.8 |
Mounting Hole Size (mm) | 389*258 |
Gross weight (kg) | 4.84 |
Installation methods | Embedded / Wall mount / Desktop |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
Power Input | 1*12VDC (6A) (Option 9~36VDC Wide-range Power Input) |
>Advantages:
The most advantages of the VFACE-156 15.6" rugged industrial computer include:
Durability: The VFACE-156 is built to withstand harsh industrial environments, with a rugged construction that can handle vibrations, shocks, and extreme temperatures.
Reliability: This industrial computer is designed for 24/7 operation, ensuring reliable performance in critical industrial applications.
High Performance: The VFACE-156 is equipped with powerful hardware components, such as a high-performance processor and ample memory, to handle demanding industrial applications with ease.
Large Display: The 15.6-inch display provides ample screen real estate for viewing and interacting with industrial applications, making it easier for operators to monitor and control processes.
Versatility: The VFACE-156 can be customized with various options, such as different input/output ports, storage options, and mounting configurations, to meet the specific needs of different industrial applications.
Longevity: With its rugged design and high-quality components, the VFACE-156 is built to last, providing a long service life and reducing the need for frequent replacements or repairs.
>Applications:
The VFACE-156 15.6" rugged industrial computer is suitable for a wide range of industrial applications, including:
Industrial Automation: The VFACE-156 can be used for controlling and monitoring automated processes in manufacturing plants, warehouses, and other industrial settings.
Machine Vision: This industrial computer is ideal for machine vision applications, such as quality control, inspection, and measurement in manufacturing processes.
HMI (Human Machine Interface): The VFACE-156 can serve as a robust HMI for interacting with industrial machinery and equipment, providing operators with a user-friendly interface for monitoring and controlling processes.
Data Acquisition: With its high-performance hardware and rugged design, the VFACE-156 is well-suited for data acquisition applications in industrial environments, such as collecting and analyzing sensor data.
Industrial IoT (Internet of Things): This industrial computer can be used as a gateway for connecting industrial devices and sensors to the IoT, enabling real-time monitoring and control of industrial processes.
Industrial Control Systems: The VFACE-156 can be integrated into industrial control systems for managing and optimizing production processes, ensuring efficient operation and high productivity.
Overall, the VFACE-156 is a versatile and reliable industrial computer that can be used in various applications across different industries to improve efficiency, productivity, and operational performance.
SKU | VFACE-156 |
Screen Size | 15.6inch |
Resolution | 1920*1080 |
Viewing Angle | 89/89/89/89 |
Brightness | 250 cd/m2 |
Contrast Ratio | 3000:1 |
Touch Screen | Capacitive, Resistive |
Controller | USB interface |
Durability | Capacitive: ≥5M times / Resistive: ≥100,000 times |
Processor | Intel® Processors |
RAM | 4G/8G/16G/32G |
SSD | under 5th Gen.: 1 * mSATA/1 *SATA(2 .5”Mechanical hard disk capacity ≤2TB) up to 6th Gen.: 1 * M.2/1 *SATA(2 .5” Mechanical hard disk capacity ≤2TB） |
Network | 1 *RTL8111 |
COM | 2 *RS232 (COM2 optional RS485) |
USB | 1* Front USB, 4* Rear USB |
Display | 1 *HDMI, 1 *VGA |
Expansion Slots | under 5th Gen.: 1 * Mini PCIE Wifi&BT or 4G LTE up to 6th Gen.: 1 * M.2(KEY EWifi&BT 2230)/1 * M.2(KEY B 4G/5G LTE 3052) |
Operating System | Windows / Linux |
Dimensions (mm) | 402.7*269.7*61.8 |
Mounting Hole Size (mm) | 389*258 |
Gross weight (kg) | 4.84 |
Installation methods | Embedded / Wall mount / Desktop |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
Power Input | 1*12VDC (6A) (Option 9~36VDC Wide-range Power Input) |
>Advantages:
The most advantages of the VFACE-156 15.6" rugged industrial computer include:
Durability: The VFACE-156 is built to withstand harsh industrial environments, with a rugged construction that can handle vibrations, shocks, and extreme temperatures.
Reliability: This industrial computer is designed for 24/7 operation, ensuring reliable performance in critical industrial applications.
High Performance: The VFACE-156 is equipped with powerful hardware components, such as a high-performance processor and ample memory, to handle demanding industrial applications with ease.
Large Display: The 15.6-inch display provides ample screen real estate for viewing and interacting with industrial applications, making it easier for operators to monitor and control processes.
Versatility: The VFACE-156 can be customized with various options, such as different input/output ports, storage options, and mounting configurations, to meet the specific needs of different industrial applications.
Longevity: With its rugged design and high-quality components, the VFACE-156 is built to last, providing a long service life and reducing the need for frequent replacements or repairs.
>Applications:
The VFACE-156 15.6" rugged industrial computer is suitable for a wide range of industrial applications, including:
Industrial Automation: The VFACE-156 can be used for controlling and monitoring automated processes in manufacturing plants, warehouses, and other industrial settings.
Machine Vision: This industrial computer is ideal for machine vision applications, such as quality control, inspection, and measurement in manufacturing processes.
HMI (Human Machine Interface): The VFACE-156 can serve as a robust HMI for interacting with industrial machinery and equipment, providing operators with a user-friendly interface for monitoring and controlling processes.
Data Acquisition: With its high-performance hardware and rugged design, the VFACE-156 is well-suited for data acquisition applications in industrial environments, such as collecting and analyzing sensor data.
Industrial IoT (Internet of Things): This industrial computer can be used as a gateway for connecting industrial devices and sensors to the IoT, enabling real-time monitoring and control of industrial processes.
Industrial Control Systems: The VFACE-156 can be integrated into industrial control systems for managing and optimizing production processes, ensuring efficient operation and high productivity.
Overall, the VFACE-156 is a versatile and reliable industrial computer that can be used in various applications across different industries to improve efficiency, productivity, and operational performance.
