The Vehicle Computer system uses a range of sensors like temperature, pressure, airflow, parking, engine speed, and position sensors, among others, to provide crucial real-time data that the computer system processes to make necessary adjustments, ensuring optimal performance, safety, and convenience.The Vehicle Computer system uses a range of sensors like temperature, pressure, airflow, parking, engine speed, and position sensors, among others, to provide crucial real-time data that the computer system processes to make necessary adjustments, ensuring optimal performance, safety, and convenience.
Vehicle Computers Series
VINCANWO
| Availability: | |
|---|---|
| Quantity: | |
In modern vehicles, a vehicle computer system is connected to multiple Electronic Control Units (ECUs) that monitor and regulate specific components or subsystems. The ECUs receive data from sensors and control various functions through actuators.
Key Features:
Touchscreen Sizes of 8", 10.1".
Pinpoint Accuracy, Timely Maintenance Reminders.
Enhanced Performance Optimization, Comprehensive System Monitoring.
Streamlined Troubleshooting Process.
Cost-Effective Repairs, Data-Driven Insights.
Applications:
Automotive: Include mechanical testing, vibration analysis, ultrasonic inspection, data logging, component testing, RADAR ranging, telematics, engine performance and ignition monitoring, CAN communication monitoring, infotainment systems (RF, audio, video, navigation, etc.), and anti-lock breaking.
| SKU | VRV80J | VRV80T (GMS) |
| Processor | Intel Celeron 2.8GHz (Quad-core) | MTK octa-core |
| Operating System | Windows 10 | Android 12 |
| RAM | 4GB LPDDR3 (Will be upgraded to 8GB) | 4GB LPDDR4X |
| SSD | 64GB EMMC (Will be upgraded to 128GB) | 64GB UFS |
| Reliability | IP65-grade waterproof and dustproof | |
| Screen | 8" LCD 16:10 (800 x 1280), 700 Nits (Will be upgraded to 1000 Nits) | |
| Battery | Optional 1000mAh/7.4V | Optional 2000mAh/3.7V |
| Communication | Dual-band WIFI / BT 5.0 / Optional 4G | Dual-band WIFI / BT 5.2 /4G |
| GNSS | GPS，GLONASS，Optional Beidou | GPS，Beidou，GLONASS |
| NFC | Optional | |
| I/O | SIM Card slot x 1(Optional) /Power interface /USB 3.0 x 1(V80J) / USB 2.0 x 1(V80T) / PORT1 (M12-12) (Optional Gigabit/100 Gigabit network interface) / PORT2 (M12-12) (Optional RS232+RS232/RS485) / PORT3 (M12-12) (USB 2.0 x 1++USB 2.0 (default) CAN x 1 + CVBS x 1 USB2.0 standard signal x 2; Optional CAN for customer debugging) | |
| Standard Accessories | WIFI Rod Antenna/ GPS Rod Antenna/ Power Cord/ 4G RRod Antenna (V80T) | |
| Optional Accessories | 4G Rod Antenna; Cigarette Lighter Adapter; Adapter; Power Adapter Cable; Wide Voltage Module; VESA Bracket; RAM Bracket; Function Adapter Cables x5; GPS Car Mushroom Antenna | |
| SKU | VRV10J | VRV10T (GMS) |
| Processor | Intel Celeron 2.8GHz (Quad-core) | MTK octa-core |
| Operating System | Windows 11 | Android 12 |
| RAM | 4GB LPDDR3 (Will be upgraded to 8GB) | 4GB LPDDR4X |
| SSD | 64GB EMMC (Will be upgraded to 128GB) | 64GB UFS |
| Reliability | IP65-grade waterproof and dustproof | |
| Screen | 10.1" LCD 16:10 (800 x 1280), 700 Nits (Will be upgraded to 1000 Nits) | |
| Battery | Optional, 1000mAh/7.4V | Optional, 2000mAh/7.4V |
| Communication | Dual-band WIFI / BT 5.0 / Optional 4G | Dual-band WIFI / BT 5.2 / 4G |
| GNSS | GPS, GLONASS, Optional Beidou,ublox M8Q | GPS, Beidou, GLONASS |
| NFC | Optional | |
| I/O | SIM Card slot x 1(Optional) /Power interface / USB 3.0 x 1(V10J) / USB 2.0 x 1(V10T) / PORT1 (M12-12) (Optional Gigabit/100 Gigabit network interface) / PORT2 (M12-12) (Optional RS232+RS232/RS485) / PORT3 (M12-12) (USB 2.0 x 1+USB 2.0 (default) /CAN x 1+CVBS x 1/ USB 2.0 x 2) | |
| Standard Accessories | WIFI Rod Antenna/ GPS Rod Antenna/ Power Cord/ 4G Rod Antenna (V10T) | |
| Optional Accessories | 4G Rod Antenna; Cigarette Lighter Adapter; Adapter; Power Adapter Cable; Wide Voltage Module; VESA Bracket; RAM Bracket; Function Adapter Cables x4; GPS Car Mushroom Antenna | |
In modern vehicles, a vehicle computer system is connected to multiple Electronic Control Units (ECUs) that monitor and regulate specific components or subsystems. The ECUs receive data from sensors and control various functions through actuators.
Key Features:
Touchscreen Sizes of 8", 10.1".
Pinpoint Accuracy, Timely Maintenance Reminders.
Enhanced Performance Optimization, Comprehensive System Monitoring.
Streamlined Troubleshooting Process.
Cost-Effective Repairs, Data-Driven Insights.
Applications:
Automotive: Include mechanical testing, vibration analysis, ultrasonic inspection, data logging, component testing, RADAR ranging, telematics, engine performance and ignition monitoring, CAN communication monitoring, infotainment systems (RF, audio, video, navigation, etc.), and anti-lock breaking.
| SKU | VRV80J | VRV80T (GMS) |
| Processor | Intel Celeron 2.8GHz (Quad-core) | MTK octa-core |
| Operating System | Windows 10 | Android 12 |
| RAM | 4GB LPDDR3 (Will be upgraded to 8GB) | 4GB LPDDR4X |
| SSD | 64GB EMMC (Will be upgraded to 128GB) | 64GB UFS |
| Reliability | IP65-grade waterproof and dustproof | |
| Screen | 8" LCD 16:10 (800 x 1280), 700 Nits (Will be upgraded to 1000 Nits) | |
| Battery | Optional 1000mAh/7.4V | Optional 2000mAh/3.7V |
| Communication | Dual-band WIFI / BT 5.0 / Optional 4G | Dual-band WIFI / BT 5.2 /4G |
| GNSS | GPS，GLONASS，Optional Beidou | GPS，Beidou，GLONASS |
| NFC | Optional | |
| I/O | SIM Card slot x 1(Optional) /Power interface /USB 3.0 x 1(V80J) / USB 2.0 x 1(V80T) / PORT1 (M12-12) (Optional Gigabit/100 Gigabit network interface) / PORT2 (M12-12) (Optional RS232+RS232/RS485) / PORT3 (M12-12) (USB 2.0 x 1++USB 2.0 (default) CAN x 1 + CVBS x 1 USB2.0 standard signal x 2; Optional CAN for customer debugging) | |
| Standard Accessories | WIFI Rod Antenna/ GPS Rod Antenna/ Power Cord/ 4G RRod Antenna (V80T) | |
| Optional Accessories | 4G Rod Antenna; Cigarette Lighter Adapter; Adapter; Power Adapter Cable; Wide Voltage Module; VESA Bracket; RAM Bracket; Function Adapter Cables x5; GPS Car Mushroom Antenna | |
| SKU | VRV10J | VRV10T (GMS) |
| Processor | Intel Celeron 2.8GHz (Quad-core) | MTK octa-core |
| Operating System | Windows 11 | Android 12 |
| RAM | 4GB LPDDR3 (Will be upgraded to 8GB) | 4GB LPDDR4X |
| SSD | 64GB EMMC (Will be upgraded to 128GB) | 64GB UFS |
| Reliability | IP65-grade waterproof and dustproof | |
| Screen | 10.1" LCD 16:10 (800 x 1280), 700 Nits (Will be upgraded to 1000 Nits) | |
| Battery | Optional, 1000mAh/7.4V | Optional, 2000mAh/7.4V |
| Communication | Dual-band WIFI / BT 5.0 / Optional 4G | Dual-band WIFI / BT 5.2 / 4G |
| GNSS | GPS, GLONASS, Optional Beidou,ublox M8Q | GPS, Beidou, GLONASS |
| NFC | Optional | |
| I/O | SIM Card slot x 1(Optional) /Power interface / USB 3.0 x 1(V10J) / USB 2.0 x 1(V10T) / PORT1 (M12-12) (Optional Gigabit/100 Gigabit network interface) / PORT2 (M12-12) (Optional RS232+RS232/RS485) / PORT3 (M12-12) (USB 2.0 x 1+USB 2.0 (default) /CAN x 1+CVBS x 1/ USB 2.0 x 2) | |
| Standard Accessories | WIFI Rod Antenna/ GPS Rod Antenna/ Power Cord/ 4G Rod Antenna (V10T) | |
| Optional Accessories | 4G Rod Antenna; Cigarette Lighter Adapter; Adapter; Power Adapter Cable; Wide Voltage Module; VESA Bracket; RAM Bracket; Function Adapter Cables x4; GPS Car Mushroom Antenna | |
