Embedded computers with Intel Core i3, i5, or i7 processors and GPIO | RK35-6L/7L

Name: Embedded computers with Intel Core i3, i5, or i7 processors and GPIO | RK35-6L/7L
Brand: VINCANWO GROUP
Rating: 5.0 (14 reviews)

"RK35-6L/7L" designation and requirements for Intel Core i3/i5/i7 + GPIO, this industrial-grade embedded computer targets demanding applications like machine vision, robotic control, and high-throughput edge analytics.

Key Highlights:

GPIO interface for connecting to external devices and sensors
High-performance processor for fast and efficient computing
Compact and rugged design for use in industrial environments
Multiple connectivity options, including Ethernet, USB, and HDMI
Support for a wide range of operating systems, including Windows and Linux

Overall, the RK35-6L/7L Industrial Mini PC GPIO is a reliable and versatile solution for industrial applications that require a compact and powerful computing device with GPIO capabilities.

Model:
Embedded computers with Intel Core i3, i5, or i7 processors and GPIO | RK35-6L/7L
Brand:
VINCANWO GROUP

Availability:

Quantity:



Inquire Add to Basket

Product Parameter

SKU	RK35-6L/7L
Processor	Intel® Core™ 6th Gen i3/i5/i7	Intel® Core™ 8th/10th Gen i3/i5/i7	Intel® Core™ 11th Gen i3/i5/i7
Memory Type	2x DDR4-3200MHz, U-DIMM, up to 64GB
Storage Type	1x MSATA		1x M.2(NVME)
Ethernet / LAN	1x Intel I210 + 1xIntel I219 + 4x Intel	2x Intel I210 + 4x Intel I226 (option POE)	2x Intel I211 + 1x Intel I226 + 4x Intel I226 (option POE)
COM	6x RS232 (COM1-2 support RS422/485)
USB	2x USB 3.0 / 2x USB2.0
Video Outputs	1x HDMI, 1x VGA
Other Interfaces	1x 4IN & OUT GPIO, 1x AUDIO (2in1)
Expansion Slots	1x M.2 Bkey option LTE 4G/5G or WIFI&BT
Operating Systems	Windows10/11, Linux
Power Input	Wide-range 9 ~ 36V DC
Dimension	180.9x109x87mm
Gross Weight	1.35kg
Mounting Options	Wall Mount, Desktop Stand
Operating Temperature	-30℃ ~ +70℃
Storage Temperature	-40℃ ~ +80℃
Humidity Rage Non-condensing	5% - 95%

RK35-6L,7L_Line drawing_Vincanwo Group

Core Specifications & Processor Tiers

Model	Processor	TDP	Industrial Use Case
RK35-6L	Intel Core i3-1215U(6C/8T)	15W	HMI, SCADA, Light Machine Vision
RK35-7L	Intel Core i7-1270PE(12C/16T)	28W	AI Inference, Real-Time Robotics
Shared Specs	GPIO: 16× digital I/O (optically isolated), -40°C to 85°C, IP67 Aluminum Housing, Dual 24V DC Inputs (9-36V)

Key Industrial Features

Industrial I/O Expansion

16× Isolated DIO (2500Vrms, 10-50V DC)
4× 16-bit ADC (0-10V), 4× PWM (5kHz)
<5 µs Interrupt Latency (Dedicated FPGA: Lattice MachXO3)

GPIO Module:
Expansion: Mini-PCIe slot for PROFINET/EtherCAT cards (e.g., Hilscher NETX 51)

Ruggedization

Vibration: 5Grms (IEC 60068-2-64)
EMC: EN 61000-6-4 (Immunity), CISPR 32 Class A (Emissions)
Conformal Coating: Humiseal 1B73 (MIL-I-46058C)

Deterministic Performance

Intel TCC/TSN: Hardware-assisted real-time via Time Coordinated Computing
Software RTOS: Preempt-RT Linux, RTX64 for Windows

Connectivity & Expansion

Interface	Industrial Application
Fieldbus	Dual CAN FD, RS-485/232 (ADM3053 isolated)
Industrial Ethernet	2× 2.5GbE w/ IEEE 802.1AS-2020 (gPTP)
GPIO Breakout	Phoenix Contact MSTB 2.5 connectors
AI Acceleration	M.2 Key-M slot for Intel Movidius Myriad X VPU
Legacy Support	Parallel port (for PLC programming)
