12.1” Core Ultra Industrial AI Panel PC | IPRO4L-121

12.1” Core Ultra Industrial Panel PC | IPRO4L-121

12.1” Core Ultra Industrial Panel PC | IPRO4L-121 is a rugged, fanless touch computer designed for harsh industrial environments, featuring powerful processing for AI tasks and robust, durable construction with options for advanced features like Hailo cards for further AI acceleration. These panel PCs offer high-resolution, touch-sensitive displays, strong performance from Intel Core Ultra processors, and features such as IP-rated housings, VESA mounting capabilities, and various connectivity options for deployment in industrial settings. Available sizes: 10.4", 12.1", 15", 15.6", 17", 19", 21.5".

Key Highlight
• Latest Fanless Meteor Lake Processor
• 12.1″ High Brightness Display with Direct Bonded Touch
• USB-C, Digital IO, HDMI Ports, Dual M.2 NVMe
• Stunning Sleek Form Factor
• Solid Cast-Aluminum Housing
• Windows 11 Pro and IOT

Model:
12.1” Core Ultra Industrial Panel PC | IPRO4L-121
Brand:
VINCANWO GROUP

Availability:

Quantity:



Inquire Add to Basket

Product Description

Model	IPRO4L-121
Primary Components	Processor Family	Intel Core Ultra Series 14th Generation Meteor Lake
	Processor Model	Core Ultra 5 - 125U
	Processor Speed	2x Low-Power Efficient Cores up to 2.1GHz, 2x Performance Cores up to 4.3GHz, 8x Efficient Cores up to 3.6GHz
	Memory Type	1x DDR5 SO-DIMM
	Memory Support	8GB, 16GB, 32GB
	Storage Type	1x M.2 M Key 2242 NVME SSD Slot, 1x M.2 M Key 2280 NVME SSD Slot
	Storage Support	128GB-1TB
Display	Screen Size	12.1"
	Resolution	1280 x 800 (WXGA)
	Screen Ratio	16:10
	Brightness	500 nits
Touch Screen	Touch Screen	Projected Capacitive (Multi-touch), Resistive
Power	Input Voltage Range	12V DC (optional 9~36V DC)
	Max Power Consumption	60W
	Standard Power Adapter	Optional 100W USB-C PD PSU, Optional 90W 3-Pin Terminal Block PSU (19V/4.74A)
Operating Systems	Windows	Windows 10 IoT, Windows 11 IoT, Windows 11 Pro
Operating Systems	Linux	Linux Ubuntu 24.04 or above (Contact your sales rep for more information)
Compatibility	Security Hardware	fTPM 2.0
Expansion Slots	Ethernet / LAN	4x LAN
	Internal M.2	1x M.2 2230 Key E (for WiFi expansion option), 1x M.2 2242 M-Key slot for NVMe SSD or AI Accelerator, 1x M.2 2280 M-Key slot for NVMe SSD
	Expansion Module support	I/O Expansion Area comes by default with 2x USB 2.0 Ports, Options for 2nd COM and 8-Pin GPIO/DIO are Available
Thermal & Environmental	Operating Temperature	-30°C ~ +70°C
	Storage Temperature	-40°C ~ +80°C
	Cooling Solution	Passive – Fanless with Heatsink
	Humidity Range	5% – 95% Non-condensing
	Storage Humidity	10% – 98% Non-condensing
Enclosure	Material	Aluminum
	IP Rating	IP65 Front Bezel
	Color	Gray
	Control Buttons	Power Button
	Mounting Options	Panel Mount, VESA 100 Mount
Peripherals & Wireless Connectivity	WiFi	Optional WiFi 6E
Peripherals & Wireless Connectivity	Bluetooth	Optional Bluetooth 5.2
Weight /Dimensions	Weight	2.8 kg
Weight /Dimensions	Dimensions	307 x 210 x 48.5 mm

Core Specifications

Category	IPRO4L-121 Specifications
Display	12.1" FHD (1920×1200) 1200 cd/m², PixelEye™ Pro (0.1% reflectivity), Dragontrail Pro Glass
Processor	Intel® Core™ Ultra 7 155U (12C/14T, 4.8GHz) w/ NPU (10 TOPS) + Arc GPU (8 Xe-cores)
Ruggedness	IP69K Front (Stainless Steel), IP54 Rear, -30°C to 70°C(Conduction-Cooled)
Memory/Storage	LPDDR5X 32GB (Solder) + 1TB NVMe Gen4 (M.2 2280, RAID 1 Optional)
Industrial I/O	4× TSN 2.5GbE (M12 X-Code), 4× USB4(40Gbps), 2× Isolated RS-485 (2kV), 8-CH DIO
Expansion	M.2 Key-B (5G/AI Accelerator), OPC UA FX 5024 (PCIe x4 Slot)
Power	24VDC ±25% (Ignition Control), PoE++ (802.3bt, 90W)
Certifications	UL 60601-1 (Medical), IEC 62443-4-2(Cybersecurity), EN 50121(Rail)
