| SKU | EX3G-8043H | |
| Dimension | 134*102*34 mm | |
| Cutout size | 120*94mm | |
| Power Consumption | 4 - 6W | |
| HMI | ||
| Features | 16.77 million true color resistive touch screen; all sizes can be displayed vertically | |
| Display type | 4.3"TFT | |
| Display size | 97*56mm | |
| Resolution (pixels) | 480*272 | |
| RAM | 128MB | |
| ROM | NAND Flash 128MB | |
| CPU | Dual core 1GHZ | |
| Operation system | Based on Linux system | |
COM Port | USB | Type-C (HMI download port); 1 USB 2.0 port |
| Other | Comes with 1 RS232 | |
| Ethernet | / | |
| programming software | Vcool | |
| PLC | ||
| I/O | Max 12DI/12DO | |
| I/O level | Input: Passive NPN, common terminal isolated; Output MT: low level NPN, COM connected to negative; Output MR: Normally open dry contact: | |
| DO type and load | Relay MR/MOS tube MOS tube: 2A/point, 4A/4-point COM,5A/12-point COM; MR: 2A/point, 5A/12 points COM | |
| High-speed counting | Conventional 6 channels single phase 60KHz or 2 channels AB (Z) phase 30KHz + 1 channel AB phase 5KHz | |
| High-speed pulse output | Conventional 8 channels: Y0-Y3 is 100KHz, Y4-Y7 is 10KHz; high-speed counting+high-speed pulse total transmission cannot exceed 480KHz | |
| COM ports | Input type | E_K_S_T_J_ type negative temperature thermocouple/PT100/PT1000/NTC10K /NTC50K/NTC100K/0-10V/0-5V/0-20mA/4-20mA or mixed type, etc. |
| Output type | 0-10V/0-5V/0-20mA/4-20mA or mixed type optional | |
| Points | Max 4AI/2AO | |
Communication interface | Default | Comes with 1 TYPE-C programming port; default 1 RS232+1 RS485 |
| Optional | Optional 1 RS485(Specially changed from the default RS232) | |
| Other | / | |
| Programming software | Compatible with PLC programming software GX Developer8.86Q and GX Works2 | |
EX3G-8043H HMI for a manufacturing plant is Human-machine interfaces (HMIs) can have many benefits, including:
Improved efficiency and productivity: HMIs can help operators monitor and control the manufacturing process more easily, which can lead to faster response times, fewer errors, and increased output.
Reduced downtime: HMIs can help facilitate remote monitoring and predictive maintenance, which can minimize downtime and improve equipment reliability.
Cost reduction: HMIs can replace hundreds of selectors, pushbuttons, and indicator lights.
Improved safety: HMIs can help operators make informed decisions quickly by providing visualizations of data, alerts, and controls.
Easier management: HMIs can help operators control the facility from central locations.
Accurate testing: HMIs can help plant managers test equipment and devices.
Customization: HMIs can allow operators to customize their screen, which can make the process more intuitive.
EX3G-8043H HMI for a manufacturing plant is software-based, so they can be adapted and adjusted very easily. EX3G-8043H HMI for a manufacturing plant
has evolved over time from simple buttons and switches to advanced touchscreens and voice commands.
