15.6” Rugged Notebook | X15T
VINCANWO
Availability: | |
---|---|
Quantity: | |
SKU | 15.6” Rugged Notebook | X15T |
Dimension (mm) | 407x305.8x45.5 |
Weight (g) | 3300 |
Device Color | Black |
LCD | 15.6'' FHD 16:9, 1920*1080,750nits |
Touch Panel | Optional 10 point capacitive, G+G |
Camera | Front 2.0MP |
Performance Parameter | Intel i5-1135G7/I7-1165G7 CPU OS: Windows 11/10 RAM: 16GB ROM: 256GB/512GB/1TB |
I/O | SD Card x 1, SIM Card x 1 USB2.0 x 1, USB3.0 x 3, HDMI x 1 DB9 (RS232) x 1, RJ45 x 2 Φ3.5mm standard earphone jack x 1 POGO 5pin x 1, DC 19V 3.42A Power connector x 1 Passenger transfer card PCIE X4 solt or HDD x 1 (Optional) Anti theft lock hole x 1, Heat dissipation air outlet (right) x 1 |
Power | AC100V ~ 240V, 50Hz/60Hz, DC 19V/3.42A |
Capacity | 7.4V/1750mAh+7.4V/6300mAh |
Type | Double Lithium-ion polymer battery |
Endurance | 8.5hrs (EM-X15U), 7+0.5hrs (EM-X15T) |
GNSS | Support GPS, Optional GPS+Beidou |
WiFi | 2.4G+5.8G, WIFI 802.11(a/b/g/n/ac) (EM-X15U) WiFi 6, 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax (EM-X15T) |
Bluetooth | BT 4.2, BT 5.1 Transmission distance: 10m |
2G/3G/4G/5G (Optional) | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD: B40, WCDMA: B1/B2/B5/B8, GSM: B2/B3/B5/B8 EM-X15T LTE-FDD B1/3/5/7/8/20 ,LTE-TDD B40 WCDMA B1/5/8,GSM 900/1800 5G NR: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/ n38/n40/n41/n48*/ n66/n71/n77/n78/n79, LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/ B19/B20/B25/B26/B28/B29/B30/B32/B66/B71, LTE-TDD: B34/B38/B39/B40/B41/B42/B43/B48, LAA: B46, WCDMA: B1/B2/B3/B4/B5/B6/B8/B19 |
NFC | Optional, 13.56MHz, Support ISO/IEC 14443A/B/15693/18092/mifare protocols Card reading distance: 4cm |
Fingerprint | SPI fingerprint (Power on login) |
IP Grade | IP65 |
Operating Temperature | -30 ~ +70°C |
Storage Temperature | -40 ~ +80°C |
Storage Humidity *Non-condensing | 5 ~ 95% |
>Product Advantage
· Durability:
Built to withstand rough handling, accidental drops, and impacts. And often built to military-grade specifications.
· Portability:
Designed to be portable, so you can use our Rugged Notebook 15.6” | X15T in extreme settings, and comes with carrying handles.
· Adaptability:
Can be tailored to your specific needs, with flexible expansion options.
· Long-lasting battery:
Have long-lasting batteries that can last hours without recharging. And come with hot-swappable batteries.
· Readability:
Have displays that are sunlight-readable and deliver sharp images and vibrant colors.
· Connectivity:
Have versatile ports that allow you to connect to specialized equipment, peripherals, or network resources.
>Product Applications
Industries
· Construction:
Using by project managers, architects, and engineers to access blueprints, design software, and project management tools
· Military:
Using in demanding field operations
· Public safety:
Using in public safety roles
· Energy:
Using in the energy industry
· Manufacturing:
Using in manufacturing industries
· Surveying:
Using in geospatial surveying, agriculture, and geology
Outdoor activities
· Hiking: For communication, navigation, and entertainment
· Camping: For communication, navigation, and entertainment
· Extreme: For communication, navigation, and entertainment
Features
· Durability: Designed to withstand dust, dirt, vibrations, and other harsh conditions
· Performance: High-performance features and robust build
· Flexibility: Customized to add ports, connections
