Industrial Monitors | OPX Series
VINCANWO GROUP
| Availability: | |
|---|---|
| Quantity: | |
| Screens | Ratio Screens | Wide Screens | |||||||
| SKU | OPX-15 | OPX-17 | OPX-19 | OPX-156 | OPX-185 | OPX-215 | OPX-236 | OPX-27 | OPX-32 |
| Screen Size | 15" | 17" | 19" | 15.6" | 18.5" | 21.5" | 23.6" | 27" | 32" |
| Resolution | 1024x768 | 1280x1024 | 1280x1024 | 1366x768 | 1920x1080 | 1920x1080 | 1920x1080 | 1920x1080 | 1920x1080 |
| Viewing Angle | 89/89/89/89 | 85/85/80/80 | 85/85/80/80 | 45/45/20/40 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 |
| Brightness | 350 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ | 220 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ | 250 cd/㎡ |
| Touch Screen | Capacitive | ||||||||
| Controller | USB Interface | ||||||||
| Durability | ≥ 5M times | ||||||||
| USB | 1x USB cable for touchscreen connection | ||||||||
| Display | 1x HDMI, 1x VGA | ||||||||
| Dimension | 358.4x286.7x49.5mm | 384.1x316.2x50.7mm | 429x356.5x49.2mm | 392x242x49.5mm | 457.2x281.7x49.6mm | 533.6x320.9x51.3mm | 572.1x345.6x51.3mm | 657x398x51.5mm | 770.7x465.6x57.2mm |
| Mounting Hole Size | 349.4x277.2mm | 381x312.9mm | 425.5x350.5mm | 387.2x237.2mm | 453.4x277.5mm | 527.9x314.9mm | 567.6x341.2mm | 651.1x394.2mm | 765.6x460.3mm |
| Gross Weight | 3.70kg | 5.60kg | 6.20kg | 3.70kg | 4.10kg | 5.70kg | 6.00kg | 9.20kg | 12.5 |
| Mounting Option | Embedded, Wall Mount, Desktop | ||||||||
| Operating Temperature | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ | -30 ~ 70℃ |
| Storage Temperature | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ | -40 ~ 80℃ |
| Humidity Range Non-condending | 5% - 95% | 5% - 95% | 5% - 95% | 5% - 95% | 5% - 95% | 5% - 95% | 5% - 95% | 5% - 95% | 5% - 95% |
| Power | 12VDC (3A) <Option Wide-range Power Input 9 - 36VDC) | ||||||||
>Product Advantages:
Durability: Industrial monitors in the OPX Series are designed to withstand harsh industrial environments, including extreme temperatures, humidity, and vibration. This makes them highly durable and reliable for use in manufacturing plants, warehouses, and other industrial settings.
High performance: The OPX Series industrial monitors offer high-resolution displays with excellent clarity and color accuracy. This allows for precise monitoring and control of industrial processes, leading to improved productivity and efficiency.
Touchscreen capabilities: Many models in the OPX Series come with touchscreen functionality, making them easy to use and navigate. This allows for quick and intuitive interaction with the monitor, reducing the need for additional input devices.
Customization options: Industrial monitors in the OPX Series can be customized to meet specific requirements, such as different screen sizes, mounting options, and connectivity ports. This flexibility allows for seamless integration into existing industrial systems.
Longevity: The OPX Series industrial monitors are built to last, with a long lifespan and minimal maintenance requirements. This ensures a low total cost of ownership and reliable performance over time.
Compatibility: Industrial monitors in the OPX Series are compatible with a wide range of industrial equipment and software, making them easy to integrate into existing systems. This allows for seamless communication and data exchange between different components of the industrial process.
>Product Application
Manufacturing: Industrial monitors in the OPX Series are commonly used in manufacturing plants for monitoring and controlling production processes. They can display real-time data, production schedules, and quality control information to ensure efficient and accurate manufacturing operations.
Warehouse and logistics: Industrial monitors in the OPX Series are used in warehouses and logistics facilities for inventory management, order tracking, and shipment monitoring. They can display information about incoming and outgoing goods, as well as provide real-time updates on inventory levels and supply chain operations.
Process control: Industrial monitors in the OPX Series are essential for process control applications in industries such as oil and gas, chemical processing, and power generation. They can display critical process parameters, alarms, and control interfaces to help operators monitor and adjust production processes in real time.
Automation: Industrial monitors in the OPX Series are often integrated into automated systems for controlling robotic equipment, conveyor belts, and other industrial machinery. They provide operators with a visual interface to monitor and manage automated processes efficiently.
Surveillance and security: Industrial monitors in the OPX Series are used for surveillance and security applications in industrial facilities, such as monitoring CCTV cameras, access control systems, and alarm notifications. They can display multiple video feeds and provide real-time monitoring of security systems.
HMI (Human-Machine Interface): Industrial monitors in the OPX Series are commonly used as HMIs for interacting with industrial equipment and machinery. They can display control panels, graphical interfaces, and data visualization tools to facilitate communication between operators and machines.
