Display | Screen Size | 15" |
Screen Resolution | 1024 x 768 (XGA) |
Screen Ratio | 4:3 |
Brightness | 350 nits |
Touch Screen | Touch Screen | 5 Wire Resistive, Projected Capacitive (Multi-touch) |
Hardness | Resistive: 3H, P-cap: 7H |
Primary Components | Processor Family | Intel Core I series 12th Generation Alder Lake |
Processor Model | Core i5-1245UE |
Processor Speed | Up to 4.4 GHz |
Memory Type | 2x DDR4 SO-DIMM |
Memory Support | 4GB, 8GB, 16GB, 32GB, 64GB |
Storage Type | 1x 2.5" SATA Drive Bay for SSD/HDD, 1x M.2 2280 NVME SSD slot |
Storage Support | 128GB-2TB |
Operating Systems | Windows | Windows 10 IoT, Windows 10 Pro, Windows 11 IoT, Windows 11 Pro |
Compatibility | Security Hardware | fTPM 2.0 |
Peripherals & Wireless Connectivity | WiFi | Optional Wi-Fi 6 802.11 AX Dual Band, with Robust Flat Antennas |
Bluetooth | Optional Bluetooth 5.3 |
Sim Card | 1x SIM Card Slot |
Barcode Scanner | Optional 1D/2D Barcode Scanner |
RFID | Optional RFID Reader |
External I/O Ports | USB | 2x M12 8Pin for USB 1/2 and USB 3/4 |
Serial / Com | 2x M12 8-pin for COM |
Serial Protocol Detail | RS-232/422/485 |
Ethernet / LAN | 1x M12 8pin RJ45 Gbe LAN |
Video Outputs | Optional Display Port 1.4 through USB-C |
Other Ports | Optional 1X USB-C 3.2 through M20 connector on bottom Bezel |
Power Input Port | M12 type 5-PIN DC-in |
Power | Input Voltage Range | 12-36V DC |
Standard Power Adapter | AC 100 ~ 277V / DC output 24V, 5A, 120W, IP68 |
Expansion Slots | Internal M.2 | 1x M.2 2230 Key E (for WiFi expansion option), 1x M.2 3042/3052 Key B (For 4G/5G Cellular expansion option), 1x M.2 for NVME SSD Support |
Thermal & Environmental | Operating Temperature | -30°C - +70°C |
Storage Temperature | -40°C - +80°C |
Cooling Solution | Passive – Fanless |
Humidity Range | 10% – 90% Non-condensing |
Enclosure | Material | Optional SUS316 Stainless Steel, SUS304 Stainless Steel |
IP Rating | IP66, IP69K, NEMA 4X |
Color | Stainless Steel |
Control Buttons | Brightness Down, Brightness Up, Power Button |
Mounting Options | Floor Stand, Swing Arm, Table Mount, VESA 100 Mount, Wall Mount |
Weight / Dimensions | Weight | 8.4 kg |
Dimensions | 395 x 309.5 x 58 mm |
Certification | Certifications | CE, FCC |
